TABLE 2: GENERAL DATA 8 TO 15 TONS
MODEL DHH: 096 120 144 180
NOMINAL COOLING (TONS) 8 10 12 15
CALCULATED EER
*
9.4 8.8 8.6 7.4
COOLING PERFOMANCE
GROSS COOLING CAPACITY (BTUH) 100500 124400 154200 191600
DESIGN CFM 3000 3800 4600 5600
SYSTEM POWER (KW) 10.22 13.35 17.11 24.20
COMPRESSOR-TYPE SCROLL SCROLL SCROLL SCROLL
NUMBER USED 2 2 2 2
EVAPORATOR COIL-TYPE COPPER TUBES, ALUMINUM FINS"
FACE AREA (SQ FT) 6.86 7.99 9.72 10.89
ROWS/FPI 4/12 4/14 4/12 4/12
REFRIGERANT CONTROL TX VALVE TX VALVE TX VALVE TX VALVE
CONDENSER COIL-TYPE COPPER TUBES, ALUMINUM FINS
FACE AREA (SQ FT) 9.03 9.03 14.00 14.00
ROWS/FPI 5/16 5/16 6/14 6/14
EVAPORATOR FAN-TYPE
"CENTRIFUGAL, FORWARD CURVED"
NUMBER USED 1 1 1 1
DIAMETER x WIDTH (IN) 15 x 11 15 x 11 15 x 15 15 x 15
DRIVE BELT
MOTOR HP (STANDARD/OVERSIZED) 1.5/2 3/NA 3/5 5/NA
CONDENSER FAN-TYPE "CENTRIFUGAL, FORWARD CURVED"
NUMBER USED 1 1 1 1
DIAMETER x WIDTH (IN) 15 x 15 15 x 15 15 x 15 15 x 15
DRIVE
MOTOR HP (STANDARD) 3 5 5 7.5
FILTERS
NUMBER USED-SIZE (IN) 2-20 x 25 x 2
3-16 x 25 x
2
4-14 x 20 x 2 6-14 x 20 x 2
CONDENSATE CONNECTION 3/4 NPT
OPERATING 1220 1260 1625 1785
SHIPPING 1305 1330 1780 1940
*. PER ARI STANDARDS 360
