036-21187-001 REV A (0301)
6 Unitary Products Group
TABLE 3: COOLING PERFORMANCE DATA - DHH024
DHH024
2 TON
AMBIENT CONDENSER AIR TEMPERATURE
85°F95°F105°F115°F
EWB EWB EWB EWB
62°F67°F72°F62°F67°F72°F62°F67°F72°F62°F67°F72°F
CFM EDB TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC
75°F 24.7 17.8 27.1 14.3 29.6 10.8 23.8 17.3 26.1 13.7 28.5 10.5 22.8 16.6 25.0 13.5 27.2 10.0 21.7 16.2 23.6 12.9 25.0 9.1
700 80°F 24.7 20.9 27.1 17.4 29.6 14.0 23.8 20.4 26.1 17.0 28.5 13.6 22.8 19.9 25.0 16.7 27.2 13.1 21.7 19.4 23.6 16.0 25.0 11.6
85°F 24.7 24.0 27.1 20.5 29.6 17.1 23.8 23.5 26.1 20.2 28.5 16.7 23.1 23.1 25.0 19.8 27.2 16.2 22.2 22.2 23.6 19.2 25.0 14.1
75°F 25.4 18.9 27.7 15.0 30.2 11.1 24.4 18.3 26.6 14.4 29.2 10.7 23.4 17.8 25.5 14.1 27.8 10.2 22.3 17.4 24.1 13.4 25.7 9.4
800 80°F 25.4 22.3 27.7 18.5 30.2 14.5 24.4 21.8 26.6 18.0 29.2 14.2 23.4 21.4 25.5 17.6 27.8 13.7 22.3 20.9 24.1 17.1 25.7 12.1
85°F 25.7 25.7 27.7 21.9 30.2 18.0 25.1 25.1 26.6 21.6 29.2 17.7 24.2 24.2 25.5 21.1 27.8 17.2 23.0 23.0 24.1 20.6 25.7 14.6
75°F 25.9 19.8 28.3 15.6 30.8 11.3 24.9 19.3 27.2 15.2 29.7 10.9 23.8 18.8 26.0 14.8 28.3 10.4 22.5 18.3 24.5 14.2 26.2 9.6
900 80°F 25.9 23.6 28.3 19.5 30.8 15.1 24.9 23.1 27.2 19.1 29.7 14.7 23.8 22.7 26.0 18.6 28.3 14.2 22.5 22.1 24.5 18.1 26.2 12.5
85°F 26.6 26.6 28.3 23.3 30.8 19.0 25.7 25.7 27.2 23.0 29.7 18.6 25.0 25.0 26.0 22.5 28.3 18.1 23.9 23.9 24.5 22.0 26.2 15.5
TABLE 4: COOLING PERFORMANCE DATA - DHH036
DHH036
3 TON
AMBIENT CONDENSER AIR TEMPERATURE
85°F95°F
105°F
115°F
EWB EWB EWB
EWB
62°F67°F
72°F
62°F67°F72°F62°F67°F72°F
62°F
67°F72°F
CFM EDB TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC
1000
75°F 34.5 25.6 38.2 20.7 40.9 15.1 33.2 24.9 36.2 19.6 39.2 14.5 31.9 24.2 34.8 19.0 37.8 14.1 30.5 23.3 33.3 18.5 36.1 13.2
80°F 34.5 30.1 38.2 25.5 40.9 19.7 33.2 29.5 36.2 24.2 39.2 19.1 31.9 28.8 34.8 23.6 37.8 18.7 30.5 27.8 33.3 23.1 36.1 16.9
85°F 34.5 34.5 38.2 30.4 40.9 24.2 33.8 33.8 36.2 28.8 39.2 23.7 32.7 32.7 34.8 28.3 37.8 23.3 31.5 31.5 33.3 27.7 36.1 20.6
1200
75°F 35.6 27.6 39.1 21.9 42.0 15.7 34.2 27.2 37.2 20.9 40.2 15.1 32.8 26.3 35.7 20.3 38.7 14.7 31.3 25.6 34.1 19.7 37.0 13.5
80°F 35.6 33.0 39.1 27.5 42.0 21.0 34.2 32.7 37.2 26.3 40.2 20.4 32.8 31.6 35.7 25.7 38.7 20.0 31.3 30.9 34.1 25.1 37.0 17.7
85°F 37.0 37.0 39.1 33.1 42.0 26.3 35.8 35.8 37.2 31.6 40.2 25.7 34.4 34.4 35.7 31.1 38.7 25.2 33.1 33.1 34.1 30.4 37.0 22.0
1400
75°F 36.4 29.6 39.8 23.2 42.9 16.2 34.9 28.9 37.9 22.2 41.0 15.7 33.5 28.3 36.4 21.7 39.5 15.2 31.8 27.6 34.7 21.1 37.8 13.8
80°F 36.4 35.7 39.8 29.5 42.9 22.2 34.9 34.9 37.9 28.3 41.0 21.6 33.5 33.5 36.4 27.8 39.5 21.2 31.8 31.8 34.7 27.2 37.8 18.6
85°F 38.4 38.4 39.8 35.9 42.9 28.3 37.1 37.1 37.9 34.4 41.0 27.7 35.7 35.7 36.4 34.0 39.5 27.2 33.8 33.8 34.7 33.3 37.8 23.4
TABLE 5: COOLING PERFORMANCE DATA - DHH048
DHH048
4 TON
AMBIENT CONDENSER AIR TEMPERATURE
85°F95°F105°F115°F
EWB EWB EWB EWB
62°F67°F72°F62°F67°F72°F62°F67°F72°F62°F67°F72°F
CFM EDB TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC
1450
75°F 47.5 35.8 51.6 28.0 56.0 20.7 45.8 35.0 49.6 27.3 53.8 20.1 43.2 33.6 47.4 26.4 51.6 19.5 41.8 33.1 45.3 25.6 48.6 18.3
80°F 47.5 42.4 51.6 34.6 56.0 27.3 45.8 41.6 49.6 33.9 53.8 26.7 43.2 40.1 47.4 33.0 51.6 26.0 41.8 39.7 45.3 32.2 48.6 24.4
85°F 48.4 48.4 51.6 41.3 56.0 33.9 46.9 46.9 49.6 40.6 53.8 33.3 45.1 45.1 47.4 39.7 51.6 32.6 43.4 43.4 45.3 38.9 48.6 30.6
1600
75°F 48.2 37.3 52.4 29.1 56.9 21.2 46.4 36.4 50.3 28.3 54.6 20.7 44.2 35.4 48.1 27.5 52.4 20.0 42.2 34.5 45.9 26.6 49.4 18.8
80°F 48.2 44.4 52.4 36.3 56.9 28.4 46.4 43.6 50.3 35.5 54.6 28.0 44.2 42.6 48.1 34.7 52.4 27.1 42.2 41.8 45.9 33.8 49.4 25.5
85°F 49.8 49.8 52.4 43.6 56.9 35.6 48.2 48.2 50.3 42.7 54.6 35.3 46.4 46.4 48.1 41.9 52.4 34.3 44.6 44.6 45.9 41.0 49.4 32.3
1800
75°F 49.0 39.1 53.2 30.2 57.8 21.7 47.1 38.2 51.1 29.5 55.4 21.1 44.8 37.2 48.8 28.6 53.2 20.5 42.8 36.3 46.6 27.9 50.4 19.6
80°F 49.0 47.0 53.2 38.1 57.8 29.6 47.1 46.2 51.1 37.4 55.4 28.8 44.8 44.8 48.8 36.5 53.2 28.3 42.8 42.8 46.6 35.8 50.4 27.1
85°F 51.2 51.2 53.2 46.1 57.8 37.5 49.7 49.7 51.1 45.3 55.4 36.7 47.6 47.6 48.8 44.4 53.2 36.1 46.0 46.0 46.6 43.8 50.4 34.7
