036-21187-001 REV A (0301)
Unitary Products Group 7
TABLE 6: COOLING PERFORMANCE DATA - DHH060
DHH060
5 TON
AMBIENT CONDENSER AIR TEMPERATURE
85°F95°F105°F115°F
EWB EWB EWB EWB
62°F67°F72°F62°F67°F72°F62°F67°F72°F62°F67°F72°F
CFM EDB TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC
1800
75°F 58.8 44.3 63.8 34.7 69.2 25.7 56.6 43.2 61.4 33.8 66.6 24.9 54.1 42.0 58.8 32.8 63.8 24.1 51.6 40.8 56.1 31.7 61.0 23.3
80°F 58.8 52.5 63.8 42.8 69.2 33.9 56.6 51.4 61.4 42.0 66.6 33.1 54.1 50.3 58.8 41.0 63.8 32.2 51.6 49.1 56.1 39.9 61.0 31.4
85°F 59.8 59.8 63.8 51.1 69.2 42.0 58.0 58.0 61.4 50.2 66.6 41.2 56.0 56.0 58.8 49.2 63.8 40.3 53.9 53.9 56.1 48.1 61.0 39.5
2000
75°F 59.8 46.4 64.8 36.0 70.3 26.3 57.5 45.2 62.4 35.1 67.6 25.6 54.7 43.8 59.6 34.0 64.8 24.7 52.3 42.8 56.8 33.0 61.9 23.7
80°F 59.8 55.3 64.8 44.9 70.3 35.2 57.5 54.2 62.4 44.1 67.6 34.6 54.7 52.7 59.6 43.0 64.8 33.6 52.3 51.8 56.8 42.0 61.9 32.7
85°F 61.7 61.7 64.8 53.9 70.3 44.1 59.8 59.8 62.4 53.2 67.6 43.8 57.6 57.6 59.6 52.0 64.8 42.5 55.4 55.4 56.8 50.9 61.9 41.5
2200
75°F 60.6 48.3 65.6 37.5 71.2 26.8 58.2 47.2 63.1 36.4 68.4 26.1 55.6 45.9 60.4 35.4 65.6 25.3 53.0 44.9 57.5 34.4 62.6 24.5
80°F 60.6 58.0 65.6 47.5 71.2 36.4 58.2 56.9 63.1 46.2 68.4 35.7 55.6 55.6 60.4 45.2 65.6 34.0 53.0 53.0 57.5 44.1 62.6 34.0
85°F 63.3 63.3 65.6 57.5 71.2 46.0 61.3 61.3 63.1 56.0 68.4 45.3 59.1 59.1 60.4 55.0 65.6 44.5 56.8 56.8 57.5 53.8 62.6 43.5
TABLE 7: COOLING PERFORMANCE DATA - DHH096
DHH096
8 TON
AMBIENT CONDENSER AIR TEMPERATURE
85°F95°F105°F115°F
EWB EWB EWB EWB
62°F67°F72°F62°F67°F72°F62°F67°F72°F62°F67°F72°F
CFM EDB TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC
3000
75°F 96.5 73.5 104.6 57.5 113.8 42.3 92.4 71.4 100.5 55.9 109.8 41.1 88.8 69.9 96.6 54.5 105.3 39.9 84.8 68.0 92.7 53.1 101.6 38.9
80°F 96.5 87.3 104.6 71.4 113.8 58.1 92.4 85.2 100.5 69.9 109.8 54.9 88.8 83.9 96.6 68.4 105.3 53.4 84.8 82.0 92.7 66.9 101.6 52.4
85°F 98.7 98.7 104.6 85.3 113.8 69.8 95.4 95.4 100.5 83.9 109.8 68.6 92.4 92.4 96.6 82.3 105.3 67.2 89.2 89.2 92.7 80.8 101.6 66.1
3200
75°F 97.4 75.5 105.6 58.9 114.9 42.9 93.3 73.8 101.6 57.4 110.8 41.7 89.4 71.8 97.5 55.8 106.2 40.5 85.6 70.2 93.5 54.5 102.5 39.5
80°F 97.4 90.1 105.6 73.7 114.9 57.4 93.3 88.5 101.6 72.1 110.8 56.2 89.4 86.6 97.5 70.5 106.2 54.9 85.6 85.0 93.5 69.0 102.5 53.8
85°F 100.6 100.6 105.6 88.3 114.9 71.9 96.2 96.2 101.6 86.9 110.8 70.8 94.1 94.1 97.5 85.3 106.2 69.4 90.8 90.8 93.5 83.7 102.5 68.3
3400
75°F 98.2 77.6 106.5 66.2 115.9 43.5 94.1 75.7 103.0 59.1 111.8 42.3 90.2 74.0 98.3 57.3 107.1 41.1 86.2 72.9 94.3 56.0 103.4 40.1
80°F 98.2 93.0 106.5 75.8 115.9 58.7 94.1 91.2 103.0 74.7 111.8 57.6 90.2 89.5 98.3 72.8 107.1 56.2 86.2 86.2 94.3 71.4 103.4 55.2
85°F 102.3 102.3 106.5 91.2 115.9 74.0 98.8 98.8 103.0 90.4 111.8 73.0 95.7 95.7 98.3 88.3 107.1 71.4 92.4 92.4 94.3 86.9 103.4 70.4
TABLE 8: COOLING PERFORMANCE DATA - DHH120
DHH120
10 TON
AMBIENT CONDENSER AIR TEMPERATURE
85°F95°F105°F115°F
EWB EWB EWB EWB
62°F67°F72°F62°F67°F72°F62°F67°F72°F62°F67°F72°F
CFM EDB TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC TC SC
3600
75°F 118.4 90.9 128.5 71.3 139.8 52.5 113.8 87.8 123.8 69.5 134.2 50.8 108.8 86.4 118.0 87.3 128.6 49.2 103.5 84.1 112.8 65.5 123.5 47.9
80°F 118.4 108.0 128.5 88.6 139.8 69.7 113.8 104.8 123.8 87.0 134.2 67.9 108.8 103.9 118.0 84.7 128.6 56.2 103.5 101.5 112.8 82.9 123.5 64.8
85°F 121.8 121.8 128.5 106.0 139.8 86.9 118.0 118.0 123.8 104.3 134.2 85.0 113.8 113.8 118.0 101.9 128.6 83.3 103.5 109.6 112.8 100.2 123.5 81.8
4000
75°F 120.2 95.3 130.5 74.2 141.8 53.7 115.4 53.7 125.6 72.4 136.2 52.1 110.3 90.9 119.8 70.4 130.5 50.5 105.0 88.7 114.5 68.7 125.2 49.2
80°F 120.2 114.1 130.5 93.3 141.8 72.4 115.4 112.2 125.6 91.5 136.2 70.8 110.3 109.9 119.8 89.6 130.5 69.0 105.0 105.0 114.5 87.7 123.5 67.7
85°F 125.6 125.6 130.5 112.3 141.8 91.3 121.8 121.8 125.6 110.6 136.2 89.4 117.2 117.2 119.8 108.6 130.5 87.8 112.8 112.8 114.5 106.8 125.2 86.3
4400
75°F 121.8 99.8 132.1 77.1 143.6 54.8 117.0 97.8 127.2 75.4 137.8 53.3 111.6 95.7 121.2 73.4 132.0 51.7 106.2 93.3 115.8 71.5 126.6 50.3
80°F 121.8 120.7 132.1 97.8 143.6 75.1 117.0 117.0 127.2 96.1 137.8 73.5 116.6 116.6 121.2 94.1 132.0 71.9 106.2 106.2 115.8 92.1 126.6 70.5
85°F 129.0 129.0 132.1 118.6 143.6 95.6 125.0 125.0 127.2 116.8 137.8 93.9 122.2 122.2 121.2 115.0 132.0 92.2 115.8 115.8 115.8 112.9 126.6 90.7
