York DL-10 User Manual

167791-BIM-B-0606
70 Unitary Products Group
TABLE 73: DL-08 (8.5 TON) STANDARD EFFICIENCY SUPERHEAT CHARGING
Outdoor
Temp (°F)
Superheat at Compressor Suction (°F)
Airflow = 3400 CFM
Indoor WB Temp (°F)
55 57 59 61 63 65 67 69 71 73 75
65 17.0 19.1 21.2 23.3 25.4 27.5 29.6 31.4 33.1 34.9 36.6
70 14.6 16.6 18.6 20.6 22.6 24.6 26.7 28.4 30.1 31.8 33.6
75 12.1 14.1 16.0 17.9 19.8 21.8 23.7 25.4 27.1 28.8 30.5
80 9.7 11.5 13.4 15.2 17.1 18.9 20.8 22.4 24.1 25.8 27.4
85 7.2 9.0 10.8 12.5 14.3 16.0 17.8 19.4 21.1 22.7 24.4
90 - - 6.6 8.7 10.7 12.7 14.8 16.7 18.7 20.7 22.7
95 - - - - 7.1 9.4 11.7 14.0 16.3 18.7 21.0
100 - - - - 5.3 7.0 8.8 11.0 13.2 15.5 17.7
105 - - - - - - 5.8 8.0 10.1 12.3 14.4
110 --------7.0 9.1 11.1
115 ---------5.9 7.8
TABLE 74: DL -10 (10 TON) STANDARD EFFICIENCY SUPERHEAT CHARGING
Outdoor
Temp (°F)
Superheat at Compressor Suction (°F)
Airflow = 4000 CFM
Indoor WB Temp (°F)
55 57 59 61 63 65 67 69 71 73 75
65 19.6 20.8 22.0 23.2 24.4 25.6 26.9 28.4 29.9 31.4 32.9
70 14.4 16.0 17.5 19.0 20.5 22.0 23.5 25.4 27.3 29.2 31.0
75 9.3 11.1 12.9 14.7 16.6 18.4 20.2 22.4 24.7 26.9 29.1
80 - 6.3 8.4 10.5 12.6 14.8 16.9 19.5 22.0 24.6 27.2
85 - - - 6.3 8.7 11.1 13.6 16.5 19.4 22.4 25.3
90 - - - 5.6 7.8 9.9 12.0 15.0 17.9 20.8 23.7
95 - - - - 6.8 8.7 10.5 13.4 16.3 19.3 22.2
100 - - - - 5.3 6.7 8.1 10.8 13.5 16.2 18.9
105 - - - - - - 5.7 8.1 10.6 13.1 15.5
110 - - - - - - - 5.5 7.7 10.0 12.2
115 ---------6.9 8.9
