RECOMMENDED FILTER SIZE/ADD-ON COOLING
NOTE:1. Special floor base or air conditioning coil required for use on combustible floor.
NOTE:2. Line contact only permitted between lines formed by the intersection of the rear panel and side panel (top in horizontal position) of the furnace jacket and
building joists, studs or framing.
* Cabinet clearance is "0", vent clearance is required.
ACCESSORIES
PROPANE CONVERSION KIT (STANDARD) –
1NP0366
This accessory conversion kit may be used to convert natural
gas units for propane (LP) operation at altitudes 0-2,000 ft..
Con version must be made by qualified distributor or dealer
personnel.
PROPANE CONVERSION KIT (HIGH ALTITUDE) –
1NP0367
This accessory conversion kit may be used to convert natural
gas units for propane (LP) operation at altitudes from 2,000 to
8,000 ft.. Conversion must be made by qualified distributor or
dealer personnel.
COMBUSTIBLE FLOOR BASE
This accessory is used for downflow applications on combus-
tible surfaces.
17-1/2" "B" Cabinets 1FB0318
21" "C" Cabinets 1FB0319
24-1/2" "D" Cabinets 1FB0320
BOTTOM EXTERNAL FILTER RACK
This accessory is used to upflow/bottom return air applica-
tions.
17-1/2" "B" Cabinets 1BR0312
21" "C" Cabinets 1BR0316
24-1/2" "D" Cabinets 1BR0320
UPFLOW / HORZ.
MODELS
FILTER SIZE ADD-ON COOLING
APPROX. OPER.
WEIGHT
Side
1
1 All filters must be external to the cabinet.
Bottom / End Downflow Tons
CFM @ .5 ESP
2
2 ESP (External Static Pressure) .5” W.C. is at furnace outlet ahead of cooling coil.
NOTE:
Filters must be field supplied
High velocity type must be used.
Air flows above 1800 CFM require either return from two sides or bottom.
UNIT CLEARANCES TO COMBUSTIBLES
G8C05012MUB11 25 x 16 24 x 15 (2) 10 x 20
2, 2-
1/
2
, 3
1200 112
G8C07512MUB11 25 x 16 24 x 15 (2) 14 x 20 2, 2-
1/
2
, 3 1200 118
G8C07516MUC11 25 x 16 24 x 18 (2) 16 x 20 2-
1/
2
, 3, 3-
1/
2
, 4 1600 129
G8C10016MUC11 25 x 16 24 x 18 (2) 16 x 20
2-
1/
2
, 3, 3-
1/
2
, 4
1600 135
G8C10020MUD11 (2) 25 x 16 24 x 21 (2) 20 x 20
3, 3-
1/
2
, 4, 5
2000 149
G8C12520MUD11 (2) 25 x 16 24 x 21 (2) 20 x 20
3, 3-
1/
2
, 4, 5
2000 155
G8C15020UHD11 (2) 25 x 16 24 x 21 N/A
3, 3-
1/
2
, 4, 5
2000 165
APPLICATION TOP FRONT REAR
LEFT
SIDE
RIGHT
SIDE
FLUE
FLOOR /
BOTTOM
CLOSET ALCOVE ATTIC
LINE
CONTACT
UPFLOW 1 6 0 0 0 6 COMBUSTIBLE YES YES YES NO
UPFLOW
B-VENT
1 2 0 0 0 1 COMBUSTIBLE YES YES YES NO
HORIZONTAL 0 6 0 0 1 6 COMBUSTIBLE NO YES YES
YES(See Note
2
)
HORIZONTAL
B-VENT
1 2 0 0 1 1 COMBUSTIBLE NO YES YES
YES(See Note
2
)
DOWNFLOW 1 6 0 0 5* 6
1" (See Note
1
)
YES YES YES NO
DOWNFLOW
B-VENT
12 0 0 01
1" (See Note
1)
YES YES YES NO
