Motor voltage is 115VAC.
DUAL RETURN (TWO SIDES OR ONE-SIDE & BOTTOM)
50 (14.7)
1
B
High 1507 1433 1371 1300 1223 1132 1040 938 42.7 40.6 38.8 36.8 34.6 32.1 29.4 26.6
Med 1239 1215 1175 1144 1085 1012 938 838 35.1 34.4 33.3 32.4 30.7 28.7 26.6 23.7
Low 907 907 891 875 849 800 741 672 25.7 25.7 25.2 24.8 24.0 22.7 21.0 19.0
75 (22.0)
1
B
High 1634 1562 1484 1417 1340 1238 1154 1030 46.3 44.2 42.0 40.1 37.9 35.1 32.7 29.2
Med 1243 1228 1214 1184 1133 1079 999 912 35.2 34.8 34.4 33.5 32.1 30.6 28.3 25.8
Low 886 886 886 886 865 823 777 700 25.1 25.1 25.1 25.1 24.5 23.3 22.0 19.8
75 (22.0)
1
C
High 1978 1896 1803 1693 1589 1478 1366 1235 56.0 53.7 51.1 47.9 45.0 41.9 38.7 35.0
Med 1682 1657 1606 1530 1455 1366 1265 1137 47.6 46.9 45.5 43.3 41.2 38.7 35.8 32.2
Low 1235 1235 1235 1235 1198 1154 1083 987 35.0 35.0 35.0 35.0 33.9 32.7 30.7 27.9
100 (29.3)
1
C
High 2122 2027 1916 1821 1717 1590 1462 1312 60.1 57.4 54.3 51.6 48.6 45.0 41.4 37.2
Med 1667 1696 1656 1597 1523 1438 1330 1191 47.2 48.0 46.9 45.2 43.1 40.7 37.7 33.7
Low 1130 1145 1177 1194 1181 1146 1077 982 32.0 32.4 33.3 33.8 33.4 32.5 30.5 27.8
100 (29.3)
2
D
High 2350 2248 2129 2015 1876 1745 1596 1425 66.5 63.7 60.3 57.1 53.1 49.4 45.2 40.4
Med-High 2122 2018 1926 1824 1722 1606 1458 1311 60.1 57.1 54.5 51.6 48.8 45.5 41.3 37.1
Med-Low 1958 1875 1782 1690 1608 1491 1364 1213 55.4 53.1 50.5 47.9 45.5 42.2 38.6 34.3
Low 1820 1757 1664 1594 1506 1405 1287 1137 51.5 49.8 47.1 45.1 42.6 39.8 36.4 32.2
125(36.6)
2
D
High 2483 2392 2282 2161 2032 1887 1739 1567 70.3 67.7 64.6 61.2 57.5 53.4 49.2 44.4
Med-High 2198 2123 2039 1930 1830 1708 1550 1413 62.2 60.1 57.7 54.7 51.8 48.4 43.9 40.0
Med-Low 1999 1916 1859 1778 1684 1576 1451 1315 56.6 54.3 52.6 50.3 47.7 44.6 41.1 37.2
Low 1832 1775 1709 1642 1556 1450 1335 1209 51.9 50.3 48.4 46.5 44.1 41.1 37.8 34.2
150 (44.0)
2
D
High 2570 2462 2361 2244 2128 1983 1826 1655 72.8 69.7 66.9 63.5 60.3 56.2 51.7 46.9
Med-High 2205 2105 2033 1952 1865 1738 1617 1459 62.4 59.6 57.6 55.3 52.8 49.2 45.8 41.3
Med-Low 1993 1931 1869 1880 1708 1590 1485 1330 56.4 54.7 52.9 53.2 48.4 45.0 42.1 37.7
Low 1831 1782 1722 1660 1575 1477 1364 1231 51.8 50.5 48.8 47.0 44.6 41.8 38.6 34.9
BOTTOM/END RETURN
50 (14.7)
1
B
High 1419 1357 1297 1212 1131 1050 942 846 40.2 38.4 36.7 34.3 32.0 29.7 26.7 24.0
Med 1221 1185 1145 1092 1036 961 879 780 34.6 33.6 32.4 30.9 29.3 27.2 24.9 22.1
Low 920 902 883 860 818 761 711 639 26.1 25.5 25.0 24.4 23.2 21.5 20.1 18.1
75 (22.0)
1
B
High 1552 1491 1420 1348 1271 1185 1080 970 43.9 42.2 40.2 38.2 36.0 33.6 30.6 27.5
Med 1229 1237 1198 1164 1105 1039 956 861 34.8 35.0 33.9 33.0 31.3 29.4 27.1 24.4
Low 889 892 879 866 846 807 760 689 25.2 25.3 24.9 24.5 24.0 22.9 21.5 19.5
75 (22.0)
1
C
High 1946 1862 1775 1620 1518 1409 1291 1160 55.1 52.7 50.3 45.9 43.0 39.9 36.6 32.8
Med 1683 1611 1551 1484 1388 1300 1190 1080 47.7 45.6 43.9 42.0 39.3 36.8 33.7 30.6
Low 1110 1138 1175 1190 1175 1126 1041 937 31.4 32.2 33.3 33.7 33.3 31.9 29.5 26.5
100 (29.3)
1
C
High 1997 1920 1822 1723 1620 1500 1355 1211 56.5 54.4 51.6 48.8 45.9 42.5 38.4 34.3
Med 1728 1679 1635 1556 1465 1359 1249 1117 48.9 47.5 46.3 44.1 41.5 38.5 35.4 31.6
Low 1131 1156 1181 1190 1171 1126 1049 926 32.0 32.7 33.4 33.7 33.2 31.9 29.7 26.2
100 (29.3)
2
D
High 2327 2232 2121 1999 1888 1763 1628 1473 65.9 63.2 60.1 56.6 53.5 49.9 46.1 41.7
Med-High 2050 1967 1868 1757 1658 1525 1403 1260 58.0 55.7 52.9 49.8 46.9 43.2 39.7 35.7
Med-Low 1911 1839 1758 1675 1593 1468 1340 1189 54.1 52.1 49.8 47.4 45.1 41.6 37.9 33.7
High 1780 1712 1642 1566 1465 1366 1249 1094 50.4 48.5 46.5 44.3 41.5 38.7 35.4 31.0
125 (36.6)
2
D
High 2397 2304 2192 2063 1955 1822 1678 1521 67.9 65.2 62.1 58.4 55.4 51.6 47.5 43.1
Med-High 2151 2063 1977 1881 1774 1652 1528 1377 60.9 58.4 56.0 53.3 50.2 46.8 43.3 39.0
Med-Low 1972 1906 1838 1748 1660 1551 1419 1282 55.8 54.0 52.0 49.5 47.0 43.9 40.2 36.3
Low 1845 1794 1721 1646 1559 1451 1344 1208 52.2 50.8 48.7 46.6 44.1 41.1 38.1 34.2
150 (44.0)
2
D
High 2488 2389 2276 2151 2024 1883 1730 1577 70.5 67.6 64.4 60.9 57.3 53.3 49.0 44.7
Med-High 2164 2084 2024 1920 1816 1692 1558 1395 61.3 59.0 57.3 54.4 51.4 47.9 44.1 39.5
Med-Low 1998 1934 1868 1773 1673 1567 1445 1294 56.6 54.8 52.9 50.2 47.4 44.4 40.9 36.6
Low 1843 1793 1728 1653 1553 1453 1328 1192 52.2 50.8 48.9 46.8 44.0 41.1 37.6 33.8
1. Return air is through side opposite motor (left side) for one side return (worst case).
2. Airflows above 1800 CFM (50.97 m
3
/min) require either return from two sides or one side plus bottom
3. Airflows expressed in standard cubic feet per minute (CFM) and in cubic meters per minute (m
3
/min).
TABLE 17: Blower Performance - CFM (Continued)
BTU/H (kW)
Input
Cabinet
Size
Speed
Tap
External Static Pressure, Inches WC External Static Pressure (kPa)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 (0.025) (0.050) (0.075) (0.099) (0.124) (0.149) (0.174) (0.199)
CFM CFM CFM CFM CFM CFM CFM CFM
m
3
/min m
3
/min m
3
/min m
3
/min m
3
/min m
3
/min m
3
/min m
3
/min
