York H5DB042 User Manual

036-21024-006 Rev. D (0403)
6 Unitary Products Group
- = Not applicable
1 PH 10 SEER AC / F2RP / RC / FP / FC (Continued)
H4DB036
F2RC/F2FC036 5,8,10,15 21 - 1200 35.4 26.2 10.10 - 9.35
F2RP/F2FP036 5,8,10,15,19 21 - 1200 36.8 27.2 10.50 - 9.65
F2RP/F2FP042 5,8,10,15 21 - 1200 37.0 27.4 10.50 - 9.60
F2FP045 5,8,10,15 24 - 1200 37.0 27.4 10.50 - 9.50
H5DB042
F2RP/F2FP042 5,8,10,15 21 - 1400 39.5 29.2 10.00 - 8.90
F2FP048 5,8,10,15,20,25 24 - 1400 40.0 29.6 10.00 - 9.00
H5DB048
F2FP048 5,8,10,15,20,25 24 - 1600 47.5 35.2 10.00 - 9.95
F2FP060 5,8,10,15,20,25 24 - 1600 48.0 35.5 10.00 - 9.85
H4DB060 F2FP060 5,8,10,15,20,25 24 - 1950 57.0 42.2 10.00 - 9.40
3 PH 10 SEER AC / F2RP / RC / FP / FC
4,5
H4DB036
F2RC/F2FC036 5,8,10,15 21 - 1200 35.0 25.9 10.00 - 9.25
F2RP/F2FP036 5,8,10,15,19 21 - 1200 36.4 26.9 10.40 - 9.55
F2RP/F2FP042 5,8,10,15 21 - 1200 36.6 27.1 10.40 - 9.50
H5DB048 F2FP048 5,8,10,15,20,25 24 - 1600 48.0 35.5 10.05 - 9.95
H4DB060 F2FP060 5,8,10,15,20,25 24 - 1950 57.0 42.2 10.00 - 9.40
3 PH SEER AC / K2EU
H4DB060 K2EU060 10,16,25 36 - 1950 56.5 39.5 10.00 - 9.40
H4DB076 K2EU090 10,16,25,36 52 - 2550 76.6 53.6 - - 10.30
1 PH 10 SEER AC / M1HC
H4DB018 M1HC018F01 0 40 - 460 16.8 12.4 10.30 - 9.60
H4DB024 M1HC024F01 0 40 - 830 24.2 17.9 11.00 - 11.10
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Single phase units require single phase 2HK heaters.
3. TXV = Use 1TV700 Series Kit.
4. To meet R=4.2 insulation requirements, substitute F2FP for F2RP, and F2FC for F2RC
. models. All ratings remain the same.
5. FG8, FG9, and FL8 furnaces and F2RP / F2RC air handlers have B.O.D. standard.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
1
MODEL
COOLING
MODEL
ELECTRIC
2
HEAT. KW
W
RATED
CFM
NET MBH
SEER
W/O TXV
SEER
+ TXV
3
EER
TOTAL SENS.
