York H5DB042 User Manual

036-21024-006 Rev. D (0403)
Unitary Products Group 7
COOLING CAPACITY - With Upflow, Downflow and Horizontal Furnace and Coils
UNIT
MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(MIN.-MAX.)
W
RATED
CFM
NET MBH
SEER W/O TDR
W/O TXV
SEER + TDR
W/O TXV
EER
TOTAL SENS.
H4DB018
575
725
14,17 G1FA024S14,17 650 18.4 13.6 10.15 - 9.10
14 G1FA030S14 650 18.8 13.9 10.30 - 9.25
- G1HD024 650 18.9 14.0 10.30 - 9.30
17 G1NA030S17H 650 19.0 14.1 10.50 - 9.35
14,17 G1UA024S14,17 650 18.4 13.6 10.15 - 9.10
14 G1UA030S14 650 18.8 13.9 10.30 - 9.25
14,17 G2FD024(S,H)14,17 650 18.8 13.9 10.30 - 9.25
17 G2FD030(S,H)17 650 19.0 14.1 10.50 - 9.35
14 G2FD035(S,H)14 650 19.0 14.1 10.50 - 9.35
H4DB024
700
900
14,17 G1FA024S14,17 800 24.6 18.2 10.30 - 9.95
14 G1FA030S14 810 24.8 18.4 10.50 - 9.75
17,21 G1FA036S17,21 800 25.0 18.5 10.60 - 10.05
17,21 G1FA036S17,21 800 25.0 18.5 - 11.00 10.05
- G1HD024 810 23.2 17.2 10.25 - 9.35
- G1HD036 810 25.6 18.9 10.80 - 9.95
17 G1NA030S17H 810 24.4 18.1 10.20 - 9.85
14,17 G1UA024S14,17 800 24.6 18.2 10.30 - 9.95
14 G1UA030S14 810 24.8 18.4 10.50 - 9.75
17,21 G1UA036S17,21 800 25.0 18.5 10.60 - 10.05
17,21 G1UA036S17,21 800 25.0 18.5 - 11.00 10.05
14,17 G2FD024S14,17 810 24.8 18.4 10.50 - 9.75
17 G2FD030(S,H)17 800 25.0 18.5 10.60 - 10.05
14 G2FD035(S,H)14 800 25.0 18.5 10.60 - 10.05
17 G2FD036(S,H)17 800 25.4 18.8 10.70 - 10.20
H4DB030
875
1125
14 G1FA030S14 1000 28.8 21.3 10.60 - 9.90
14 G1FA036S14 1000 29.0 21.5 10.80 - 10.00
17,21 G1FA036S17,21 1000 29.0 21.5 10.80 - 10.00
17 G1FA048S17 1000 30.0 22.2 - 11.00 10.20
- G1HD036 1000 29.4 21.8 10.70 - 9.95
17 G1NA030S17K 1000 29.4 21.8 10.60 - 10.05
14 G1UA030S14 1000 28.8 21.3 10.60 - 9.90
14 G1UA036S14 1000 29.0 21.5 10.80 - 10.00
17,21 G1UA036S17,21 1000 29.0 21.5 10.80 - 10.00
17 G1UA048S17 1000 30.0 22.2 - 11.00 10.20
17 G2FD030(S,H)17 1000 29.0 21.5 10.60 - 9.90
14 G2FD035(S,H)14 1000 29.0 21.5 10.75 - 9.70
17 G2FD036(S,H)17 1000 30.0 22.2 12.20 - 10.85
17 G2FD036(S,H)17 1000 30.0 22.2 - 10.90 9.95
21 G2FD036(S,H)21 1000 30.0 22.2 - 11.00 10.05
21 G2FD042(S,H)21 1000 30.0 22.2 - 11.00 10.10
17 G2FD046(S,H)17 1000 31.0 22.9 12.45 - 11.10
17 G2FD046(S,H)17 1000 30.0 22.2 - 11.00 10.05
H4DB036S06
1050
1350
14 G1FA036S14 1200 35.4 26.2 10.00 - 9.30
17,21 G1FA036S17,21 1200 35.4 26.2 10.00 - 9.30
21 G1FA048S21 1200 37.0 27.4 - 10.60 9.75
- G1HD036 1200 35.4 26.2 10.00 - 9.30
- G1HD048 1200 36.8 27.2 10.20 - 9.60
17 G1NA036S17J 1200 35.6 26.3 10.20 - 9.40
21 G1NA036S21C 1200 35.6 26.3 10.20 - 9.40
21 G1NA048S21D 1200 36.8 27.2 10.40 - 9.65
14 G1UA036S14 1200 35.4 26.2 10.00 - 9.30
17,21 G1UA036S17,21 1200 35.4 26.2 10.00 - 9.30
17 G1UA048S17 1200 37.0 27.4 - 10.55 9.70
21 G1UA048S21 1200 37.0 27.4 - 10.60 9.75
14 G2FD035(S,H)14 1200 35.2 26.0 10.00 - 9.35
17 G2FD036(S,H)17 1200 35.6 26.3 10.20 - 9.40
21 G2FD036(S,H)21 1200 36.8 27.2 10.30 - 9.50
21 G2FD042(S,H)21 1200 36.8 27.2 10.40 - 9.65
17 G2FD046(S,H)17 1200 36.6 27.1 10.40 - 9.55
21,24 G2FD048(S,H)21,24 1200 37.2 27.5 - 10.60 9.85
For Notes see Page 6.
