York J ZJ Series - JA5 ZJ Physical Dimensions

5803641-JIM-B-0620
10 Johnson Controls Ducted Systems
Figure 9: JA5ZJ Physical Dimensions
LEFT
A
59.00
C
D
E
F
4.19
27.31
89.00
21.19
11.38
15.38
59.00
15.38
29.69
15.25
FRONT
SEE DETAIL B
FOR DRAIN LOCATION
SEE DETAIL A FOR GAS INLET
B
2X Ø 24.38
