York LATITUDE Series User Manual

700699-YTG-B-0812
4 Johnson Controls Unitary Products
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
14.5 SEER AC WITH AIR HANDLERS
TCGF18S41S3(E)
AHE18B 17.5 – 610 17.9 13.0 16.25 13.25
AHE24B 17.5 – 585 18.1 13.1 16.75 13.50
AHE30B 17.5 – 585 18.1 13.1 16.75 13.50
AHE36C 21.0 – 730 19.2 15.0 17.50 14.25
AHR18B 17.5 – 665 17.7 13.1 14.25 12.00
AHV18B 17.5 – 615 17.6 12.8 16.00 13.00
AHV24B 17.5 – 580 17.8 12.9 16.50 13.25
AHV30B 17.5 – 700 18.0 13.8 16.50 13.25
AHV36C 21.0 – 670 18.2 13.7 17.00 13.75
AV*24 17.5 – 610 18.1 13.2 16.50 13.50
AV*36 21.0 – 630 18.7 13.8 17.50 14.00
MV12B 17.5 FC/MC18B 600 17.9 12.7 16.25 13.25
MV12B 17.5 FC/MC35B 600 18.2 13.1 16.50 13.25
MV12B 17.5 FC/MC43B 600 18.4 13.2 16.75 13.50
MX12B 17.5 FC/MC18B 585 17.9 12.8 16.50 13.50
MX12B 17.5 FC/MC35B 660 18.6 14.1 17.50 14.25
MX12B 17.5 FC/MC43B 620 18.5 13.3 17.50 14.00
TCGF24S41S3(E)
AHE24B 17.5 – 795 25.2 18.7 16.25 13.50
AHE30B 17.5 – 795 25.2 18.7 16.25 13.50
AHE36C 21.0 – 855 26.2 19.7 17.00 14.25
AHE42D 24.5 – 820 26.4 19.5 17.25 14.50
AHR24B 17.5 – 740 24.8 17.7 15.00 12.75
AHV24B 17.5 – 710 24.0 17.0 15.75 13.25
AHV30B 17.5 – 775 24.2 17.5 15.75 13.25
AHV36C 21.0 – 760 24.4 17.7 16.25 13.50
AV*36 21.0 – 725 25.8 18.6 16.50 13.75
MV12B 17.5 FC/MC35B 800 25.6 18.0 16.00 13.50
MV12B 17.5 FC/MC43B 800 25.8 18.4 16.10 13.75
MV12D 24.5 FC/MC48D 845 26.4 19.8 17.25 14.50
MV16C 21.0 FC/MC35C 800 25.6 18.0 16.00 13.50
MV16C 21.0 FC/MC43C 800 25.8 18.4 16.10 13.75
MV16C 21.0 FC/MC48C 800 26.2 18.7 16.50 14.00
MX12B 17.5 FC/MC35B 815 25.6 18.8 17.00 14.25
MX12B 17.5 FC/MC43B 735 25.6 18.4 16.75 14.00
TCGF30S41S3(E)
AHE30B 17.5 – 985 29.6 21.1 15.50 13.00
AHE36C 21.0 – 1000 30.4 21.9 16.25 13.75
AHE42D 24.5 – 1000 30.8 22.3 16.75 14.00
AHR30B 17.5 – 1115 29.8 21.9 14.25 12.00
AHR36B 17.5 – 1060 30.0 21.7 14.50 12.25
AHV30B 17.5 – 1000 29.0 20.7 14.75 12.50
AHV36C 21.0 – 895 29.4 20.5 16.00 13.25
AHV42D 24.5 – 1080 30.0 22.2 16.25 13.50
AV*36 21.0 – 960 30.4 22.7 16.25 13.50
MV12B 17.5 FC/MC35B 1000 29.6 21.4 15.25 13.00
MV12B 17.5 FC/MC43B 1000 30.2 22.0 15.75 13.25
MV16C 21.0 FC/MC35C 1000 29.6 21.4 15.50 13.25
MV16C 21.0 FC/MC43C 1000 30.2 22.0 16.00 13.50
MV16C 21.0 FC/MC48C 1000 30.6 22.2 16.00 13.50
MV20D 24.5 FC/MC48D 1000 30.6 22.2 16.00 13.50
MX12B 17.5 FC/MC35B 1085 30.4 22.1 16.00 13.25
For notes see Page 6.

York LATITUDE Series Specifications

General

Refrigerant	R-410A
Sound Level	As low as 72 dB
Type	Air Conditioner
Series	LATITUDE
Cooling Capacity	1.5 to 5 Tons
Compressor Type	Scroll
Warranty	10-year limited warranty on compressor
