700699-YTG-B-0812

Johnson Controls Unitary Products 3

PROCEDURES:

1. Unit factory charge listed on the unit nameplate includes refrigerant for the outdoor unit, the smallest matched indoor unit, and 15 feet of interconnecting line tubing.

2. Verify the TXV and additional charge required for specific matched indoor unit in the system using the above table.

3. Add additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.

4. For indoor matches requiring additional charge, the refrigerant needs to be weighed in for specific matched indoor unit and lineset length.

5. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + charge adder for matched indoor unit +

charge adder for line set.

System Charge for Various Matched Systems

Outdoor Unit

TCGF18

S41S3(E)

TCGF24

S41S3(E)

TCGF30

S41S3(E)

TCGF36

S41S3(E)

TCGF42

S41S3(E)

TCGF48

S41S4(E)

TCGF60

S41S4(E)

Required TXV

1,2

4F1 4F1 4G1 4G1 4G1 4J1 4J1

Indoor Unit

3,4,5

Additional Charge, oz

AHE18B 0––––––

AHE24B 1516–––––

AHE30B 151613––––

AHE36C 24 23 19 15 – – –

AHE42D – 35302517 – –

AHE48D – – – 24 16 11 –

AHE60D – – – 29221513

AHR18B 0––––––

AHR24B –16–––––

AHR30B ––12––––

AHR36B – – 19 15 – – –

AHR42C – – – 25 17 – –

AHR48D – – – – 16 11 –

AHR60D – – – – 22 15 13

AHV18B 0––––––

AHV24B 1516–––––

AHV30B 151613––––

AHV36C 23 22 19 15 – – –

AHV42D – – 31 25 17 – –

AHV48D – – – 24

16 11 –

AHV60D – – – –

21 15 13

AV*24 3–––

– – –

AV*36 23231915

– – –

AV*48 – – – 24

18 11 –

AV*60 ––––

18 11 9

FC/MC/PC18 0–––

– – –

FC/MC/PC32 15 16 13 –

– – –

FC/MC/PC35 15 16 13 –

– – –

FC/MC/PC37 23 22 19 15

– – –

FC/MC/PC43 23 22 19 15

8 – –

FC/MC/PC48 – 343025

17 9 –

FC/MC/PC60 – – – 24

16 11 9

FC/MC62 – – – 29

21 15 13

FC64 – – – 39

30 26 21

HD24 14 – – –

– – –

HD36 19 19 16 –

– – –

HD48 – 45 40 34

26 – –

HD60 – – – –

22 8 6

UC18 2 – – –

– – –

UC48 – – – –

11 10 –

UC60 – – – 24

16 13 11

Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved coil

only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.

FOOTNOTES:

1. For applications requiring a TXV use S1-1TVM*** series kit.

2. A TXV kit must be used with these indoor units to obtain system performance.

3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require blower Time Delay Kit S1-2FD06700224.

4. PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.

5. Refer to Cooling Performance Data tables for actual system performance for specified system matches.
