Natural Gas LP Gas (Requires LP conversion kit)
LP Conversion Kit Installed By
Supply static after indoor coil (in w.c.")
Return Static (in w.c.") before
Total External Static Pressure
Installation debris disposed of and furnace area cleaned up?
Explain operation of system to equipment owner
Gas Side
Air Side: System External Static Pressure
Owner Education
Additional Job Detail
Supply static before indoor coil (in w.c.")
Calculated input in btuh - clock the gas meter (Nat Gas Only)
Manifold Gas Pressure (in. w.c.")Inlet Gas Pressure (in. w.c.")
LP Gas Conversion Kit Part # Used
Return Static (in w.c.") after
Air Side: Heating
Air Side: Cooling
Air Side: Continuous Fan
Clean Up
Give owner the owner's manual provided
Gas Type
Explain thermostat use and programming (if applicable) to owner
Cycle Test
Operate the furnace through several heating cycles from the thermostat, noting and correcting any problems
Operate the furnace through continuous fan cycles from the thermostat, noting and correcting any problems
Operate the furnace through cooling cycles (as applicable), noting and correcting any problems
Heat Blower Speed Selected
Temperature rise in degrees F
Low Cool Blower Speed Selected
High Cool Blower Speed Selected
Cooling CFM delivery (use Blower Performance Data Chart)
Hi Low
Blower Speed Selected
5-Red (Low) 4-Yel (Med Lo) 3-Gray (Med)
2-Blue (Med High) 1-Black (High)
5-Red (Low) 4-Yel (Med Lo) 3-Gray (Med)
2-Blue (Med High) 1-Black (High)
5-Red (Low) 4-Yel (Med Lo) 3-Gray (Med)
2-Blue (Med High) 1-Black (High)
5-Red (Low) 4-Yel (Med Lo) 3-Gray (Med)
2-Blue (Med High) 1-Black (High)
