BLOWER PERFORMANCE CFM- UPFLOW (WITHOUT FILTER)
MODELS
Input/Output/Airflow/
cabinet
SPEED TAP
EXTERNAL STATIC PRESSURE, INCHES WC
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
40 / 37 / 1000 / "A"
HIGH 1330 1260 1210 1150 1090 1025 955 880 775 645
MED-HIGH 985 970 965 935 900 860 800 740 665 535
MED-LOW 790 780 760 740 715 685 635 575 485 365
LOW 635 625 610 590 565 535 490 435 360 250
60 / 55 / 1000 / "B"
HIGH 1360 1330 1290 1250 1190 1130 1055 970 865 735
MED-HIGH 980 970 960 945 920 870 830 775 685 575
MED-LOW 765 755 740 725 710 680 645 590 510 405
LOW 635 625 610 590 565 540 500 440 375 290
80 / 75 / 1200 / "B”
HIGH 1465 1440 1390 1365 1315 1255 1190 1125 1055 940
MED 1085 1075 1060 1045 1030 1000 960 910 830 755
LOW 805 795 785 770 755 730 700 655 615 565
80 / 75 / 1600 / "C”
HIGH 1940 1905 1870 1815 1760 1700 1620 1555 1460 1305
MED 1400 1390 1380 1370 1355 1320 1285 1255 1210 1135
LOW 1245 1225 1205 1185 1165 1145 1125 1095 1050 970
100 / 95 / 1400 / "C”
HIGH 1785 1720 1650 1575 1495 1405 1315 1190 1050 880
MED 1430 1405 1375 1340 1290 1220 1130 1025 885 730
LOW 1150 1135 1120 1080 1045 1000 925 825 700 575
100 / 95 / 2000 / "C"
HIGH 2355 2285 2205 2145 2080 1995 1905 1820 1715 1610
MED 1950 1915 1870 1830 1780 1710 1640 1560 1475 1375
LOW 1575 1555 1540 1505 1470 1430 1380 1315 1245 1150
120 / 112 / 2000 / "D”
HIGH 2375 2315 2245 2175 2100 2020 1935 1840 1755 1650
MED 1990 1955 1920 1875 1835 1775 1715 1630 1550 1450
LOW 1565 1550 1530 1505 1480 1445 1405 1350 1280 1200
140 / 130 / 2000 / "D”
HIGH 2410 2340 2265 2200 2125 2035 1960 1860 1775 1670
MED 2020 1975 1940 1895 1855 1790 1725 1655 1570 1470
LOW 1580 1565 1550 1520 1495 1460 1420 1360 1295 1210
NOTE: Data below reflects airflows with two return openings - two sides or one side and bottom.
100 / 95 / 2000 / "C"
HIGH 2365 2295 2215 2155 2090 2005 1915 1830 1725 1620
MED 1965 1930 1885 1845 1795 1725 1655 1575 1490 1390
LOW 1595 1575 1560 1525 1490 1450 1400 1335 1265 1170
120 / 112 / 2000 / "D”
HIGH 2385 2325 2255 2185 2110 2030 1945 1850 1765 1660
MED 2005 1970 1935 1890 1850 1790 1730 1645 1565 1465
LOW 1585 1570 1550 1525 1500 1465 1425 1370 1300 1220
140 / 130 / 2000 / "D”
HIGH 2420 2350 2275 2210 2135 2045 1970 1870 1785 1680
MED 2035 1990 1955 1910 1870 1805 1740 1670 1585 1485
LOW 1600 1585 1570 1540 1515 1480 1440 1380 1315 1230
Airflow expressed in standard cubic feet per minute.
Notes: 1. Return air is through side opposite motor (left side).
2. Air flows above 1800 CFM require either return from two sides or one side plus bottom.
3. Motor voltage at 115 V.
