127421-YIM-C-0606
Unitary Products Group 35
TABLE 39: 10 TON OPTIONAL MOTOR SIDE SHOT BLOWER PERFORMANCE
*
ESP
†
TURNS OPEN
‡
012345
CFM
W
**
BHP CFM
W
**
BHP CFM
W
**
BHP CFM
W
**
BHP CFM
W
**
BHP CFM
W
**
BHP
0.2
- - - - - - - - - - - - 5067 2614 2.80 4809 2290 2.46
0.4
- - - - - - 5179 3112 3.34 4884 2703 2.90 4729 2401 2.57 4459 2113 2.27
0.6
- - - - - - 4925 2943 3.16 4585 2521 2.70 4429 2244 2.41 4137 1964 2.11
0.8
- - - 4974 3220 3.45 4607 2727 2.92 4267 2342 2.51 4099 2080 2.23 3783 1809 1.94
1.0
4975 3453 3.70 4657 2995 3.21 4305 2550 2.73 3941 2171 2.33 3751 1919 2.06 3371 1630 1.75
1.2
4679 3423 3.67 4366 2808 3.01 4022 2373 2.54 3545 1978 2.12 3305 1741 1.87 - - -
1.4
4429 3065 3.29 4040 2607 2.80 3669 2673 2.87 2918 1700 1.82 - - - - - -
1.6
4107 2845 3.05 3620 2357 2.53 2931 1830 1.96 - - - - - - - - -
1.8
3553 2500 2.68 2756 1899 2.04 - - - - - - - - - - - -
2.0
2439 1939 2.08 - - - - - - - - - - - - - - -
*.
Blower performance includes two-inch throwaway filters.
†.
ESP (External Static Pressure) given is that available for the supply and return air duct system. All internal resistances have been deducted from the
total static pressure of the blower.
‡.
“Turns Open” refers to the setting of the variable pitch motor sheave, where “0 Turns Open” is fully closed.
**.
W = Watts
TABLE 40: 12-1/2 TON STANDARD MOTOR SIDE SHOT BLOWER PERFORMANCE
*
ESP
†
TURNS OPEN
‡
012345
CFM
W
**
BHP CFM
W
**
BHP CFM
W
**
BHP CFM
W
**
BHP CFM
W
**
BHP CFM
W
**
BHP
0.4
------
5201 3162 3.39 4966 2796 3.00 4681 2405 2.58 4355 2054 2.20
0.6
---
5220 3395 3.64 4942 2980 3.20 4657 2608 2.80 4358 2230 2.39 4007 1890 2.03
0.8
---
4944 3194 3.43 4661 2806 3.01 4378 2572 2.76 4016 2057 2.21
---
1.0
5003 3490 3.74 4647 2988 3.20 4380 2636 2.83 4030 2257 2.42
------
1.2
4724 3290 3.53 4363 2875 3.08 4012 2505 2.69
---------
1.4
4428 3040 3.26
---------------
*.
Blower performance includes two-inch throwaway filters.
†.
ESP (External Static Pressure) given is that available for the supply and return air duct system. All internal resistances have been deducted from the
total static pressure of the blower.
‡.
“Turns Open” refers to the setting of the variable pitch motor sheave, where “0 Turns Open” is fully closed.
**.
W = Watts
