035-17311-003-A-0704
Unitary Products Group 3
LIST OF FIGURES
Fig. # Pg.#
1 UNIT SHIPPING BRACKET . . . . . . . . . . . . . . . . . . . . 10
2 CONDENSER COVERING . . . . . . . . . . . . . . . . . . . . 10
3 COMPRESSOR SECTION . . . . . . . . . . . . . . . . . . . . . 10
4 PREDATOR
®
COMPONENT LOCATION . . . . . . . . . 11
5 UNIT 4 POINT LOAD . . . . . . . . . . . . . . . . . . . . . . . . . 12
6 UNIT 6 POINT LOAD . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 UNIT CENTER OF GRAVITY . . . . . . . . . . . . . . . . . . . 12
8 UNIT DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 13
9 BOTTOM DUCT OPENINGS (FROM ABOVE) . . . . . 14
10 REAR DUCT DIMENSIONS . . . . . . . . . . . . . . . . . . . . 14
11 PREDATOR
®
ROOF CURB DIMENSIONS . . . . . . . . 15
12 SUNLINE™ TO PREDATOR
®
TRANSITION ROOF
CURBS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Fig. #
Pg.#
13 SIDE PANELS WITH HOLE PLUGS . . . . . . . . . . . . . 16
14 RETURN DOWNFLOW PLENUM WITH PANEL . . . 16
15 DISCHARGE PANEL IN PLACE . . . . . . . . . . . . . . . . 16
16 CONDENSATE DRAIN . . . . . . . . . . . . . . . . . . . . . . . 16
17 ELECTRONIC THERMOSTAT FIELD WIRING . . . . 18
18 FIELD WIRING 24 VOLT THERMOSTAT . . . . . . . . . 18
19 FIELD WIRING DISCONNECT . . . . . . . . . . . . . . . . . 19
20 ENTHALPY SET POINT CHART . . . . . . . . . . . . . . . . 23
21 HONEYWELL ECONOMIZER CONTROL W7212 . . 23
22 BELT ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . 24
23 DRY COIL DELTA P . . . . . . . . . . . . . . . . . . . . . . . . . 32
24 BASIC TROUBLESHOOTING FLOWCHART . . . . . . 40
