York PREDATOR MagnaDRY DR090 - Dry Coil Delta P

127878-YIM-C-1208
46 Johnson Controls Unitary Products
FIGURE 31 - DRY COIL DELTA P
Indoor Coil Pressure Drop vs. Airflow
0.2
0.25
0.3
0.35
0.4
0.45
0.5
0.55
0.6
0.65
0.7
2200 3200 4200 5200 6200
Volumetric Flow Rate (cfm)
Coil Pressure Drop (iwg)
100% Return Economizer No Economizer
DR090
DR120 & DR150
MagnaDRY™ Units
