York Predator ZR series User Manual

5167540-YIM-H-0518
20 Johnson Controls Ducted Systems
Table 9: Electrical Data
ZR037-061 Standard Indoor Blower - Without Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
MCA
1
w/Pwr
Exh
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
037
(3)
208 8.7 68.0 13.5 2.1 5.2 5.5 0.0
None-- -18.223.725 30
E03 2.3 1 6.4 18.2 23.7 25 30
E06 4.5 1 12.5 22.1 29.0 25 30
E09 6.8 1 18.9 30.1 37.0 35 40
E15 11.3 2 31.4 45.7 52.6 50 60
230 8.7 68.0 13.5 2.1 5.2 5.5 0.0
None-- -18.223.725 30
E03 3.0 1 7.2 18.2 23.7 25 30
E06 6.0 1 14.4 24.5 31.4 25 35
E09 9.0 1 21.7 33.6 40.4 35 45
E15 15.0 2 36.1 51.6 58.5 60 60
460 4.6 34.0 7.1 1.3 2.6 2.2 0.0
None - - - 9.6 11.8 15 15
E03 3.0 1 3.6 9.6 11.8 15 15
E06 6.0 1 7.2 12.3 15.0 15 15
E09 9.0 1 10.8 16.8 19.5 20 20
E15 15.0 2 18.0 25.8 28.6 30 30
575 3.5 28.0 5.5 0.7 2.0 1.8 0.0
None - - - 7.0 8.8 15 15
E09 9.0 1 8.7 13.3 15.6 15 20
E15 15.0 2 14.4 20.5 22.8 25 25
049
(4)
208 11.9 88.0 18.5 2.1 5.2 5.5 0.0
None-- -24.329.835 40
E06 4.5 1 12.5 24.3 29.8 35 40
E09 6.8 1 18.9 30.1 37.0 35 40
E15 11.3 2 31.4 45.7 52.6 50 60
E20 15.0 2 41.6 58.5 65.4 60 70
230 11.9 88.0 18.5 2.1 5.2 5.5 0.0
None-- -24.329.835 40
E06 6.0 1 14.4 24.5 31.4 35 40
E09 9.0 1 21.7 33.6 40.4 35 45
E15 15.0 2 36.1 51.6 58.5 60 60
E20 20.0 2 48.1 66.6 73.5 70 80
460 5.2 44.0 8.1 1.3 2.6 2.2 0.0
None-- -11.613.815 15
E06 6.0 1 7.2 12.3 15.0 15 15
E09 9.0 1 10.8 16.8 19.5 20 20
E15 15.0 2 18.0 25.8 28.6 30 30
E20 20.0 2 24.1 33.3 36.1 35 40
575 4.8 36.0 7.5 0.7 2.0 1.8 0.0
None - - - 9.3 11.1 15 15
E09 9.0 1 8.7 13.3 15.6 15 20
E15 15.0 2 14.4 20.5 22.8 25 25
E20 20.0 2 19.2 26.6 28.8 30 30
061
(5)
208 14.1 88.0 22.0 2.1 5.2 5.5 0.0
None-- -27.032.535 45
E06 4.5 1 12.5 27.0 32.5 35 45
E09 6.8 1 18.9 30.1 37.0 40 45
E15 11.3 2 31.4 45.7 52.6 50 60
E20 15.0 2 41.6 58.5 65.4 60 70
E24 18.0 2 50.0 69.0 75.8 70 80
230 14.1 88.0 22.0 2.1 5.2 5.5 0.0
None-- -27.032.535 45
E06 6.0 1 14.4 27.0 32.5 35 45
E09 9.0 1 21.7 33.6 40.4 40 45
E15 15.0 2 36.1 51.6 58.5 60 60
E20 20.0 2 48.1 66.6 73.5 70 80
E24 24.0 2 57.7 78.7 85.5 80 90
460 7.7 55.0 12.0 1.3 2.6 2.2 0.0
None-- -14.716.920 20
E06 6.0 1 7.2 14.7 16.9 20 20
E09 9.0 1 10.8 16.8 19.5 20 20
E15 15.0 2 18.0 25.8 28.6 30 30
E20 20.0 2 24.1 33.3 36.1 35 40
E24 24.0 2 28.9 39.3 42.1 40 45
575 5.1 36.0 7.5 0.7 2.0 1.8 0.0
None - - - 9.7 11.5 15 15
E09 9.0 1 8.7 13.3 15.6 15 20
E15 15.0 2 14.4 20.5 22.8 25 25
E20 20.0 2 19.2 26.6 28.8 30 30
E24 24.0 2 23.1 31.4 33.6 35 35
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
