ZR037-061 Standard Indoor Blower - With Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
MCA
1
w/Pwr
Exh
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
037
(3)
208 8.7 68.0 13.5 2.1 5.2 5.5 10.0
None-- -28.534.035 40
E03 2.3 1 6.4 28.5 34.0 35 40
E06 4.5 1 12.5 34.6 41.5 40 45
E09 6.8 1 18.9 42.6 49.5 45 50
E15 11.3 2 31.4 58.2 65.1 60 70
230 8.7 68.0 13.5 2.1 5.2 5.5 10.0
None-- -28.534.035 40
E03 3.0 1 7.2 28.5 34.9 35 40
E06 6.0 1 14.4 37.0 43.9 40 45
E09 9.0 1 21.7 46.1 52.9 50 60
E15 15.0 2 36.1 64.1 71.0 70 80
460 4.6 34.0 7.1 1.3 2.6 2.2 5.0
None-- -14.716.915 20
E03 3.0 1 3.6 14.7 16.9 15 20
E06 6.0 1 7.2 18.5 21.3 20 25
E09 9.0 1 10.8 23.0 25.8 25 30
E15 15.0 2 18.0 32.1 34.8 35 35
575 3.5 28.0 5.5 0.7 2.0 1.8 4.0
None-- -11.213.015 15
E09 9.0 1 8.7 18.3 20.6 20 25
E15 15.0 2 14.4 25.5 27.8 30 30
049
(4)
208 11.9 88.0 18.5 2.1 5.2 5.5 10.0
None-- -34.339.845 50
E06 4.5 1 12.5 34.6 41.5 45 50
E09 6.8 1 18.9 42.6 49.5 45 50
E15 11.3 2 31.4 58.2 65.1 60 70
E20 15.0 2 41.6 71.0 77.9 80 80
230 11.9 88.0 18.5 2.1 5.2 5.5 10.0
None-- -34.339.845 50
E06 6.0 1 14.4 37.0 43.9 45 50
E09 9.0 1 21.7 46.1 52.9 50 60
E15 15.0 2 36.1 64.1 71.0 70 80
E20 20.0 2 48.1 79.1 86.0 80 90
460 5.2 44.0 8.1 1.3 2.6 2.2 5.0
None-- -16.618.820 20
E06 6.0 1 7.2 18.5 21.3 20 25
E09 9.0 1 10.8 23.0 25.8 25 30
E15 15.0 2 18.0 32.1 34.8 35 35
E20 20.0 2 24.1 39.6 42.3 40 45
575 4.8 36.0 7.5 0.7 2.0 1.8 4.0
None-- -13.315.115 20
E09 9.0 1 8.7 18.3 20.6 20 25
E15 15.0 2 14.4 25.5 27.8 30 30
E20 20.0 2 19.2 31.6 33.8 35 35
061
(5)
208 14.1 88.0 22.0 2.1 5.2 5.5 10.0
None-- -37.042.550 50
E06 4.5 1 12.5 37.0 42.5 50 50
E09 6.8 1 18.9 42.6 49.5 50 50
E15 11.3 2 31.4 58.2 65.1 60 70
E20 15.0 2 41.6 71.0 77.9 80 80
E24 18.0 2 50.0 81.5 88.3 90 90
230 14.1 88.0 22.0 2.1 5.2 5.5 10.0
None-- -37.042.550 50
E06 6.0 1 14.4 37.0 43.9 50 50
E09 9.0 1 21.7 46.1 52.9 50 60
E15 15.0 2 36.1 64.1 71.0 70 80
E20 20.0 2 48.1 79.1 86.0 80 90
E24 24.0 2 57.7 91.2 98.0 100 100
460 7.7 55.0 12.0 1.3 2.6 2.2 5.0
None-- -19.721.925 25
E06 6.0 1 7.2 19.7 21.9 25 25
E09 9.0 1 10.8 23.0 25.8 25 30
E15 15.0 2 18.0 32.1 34.8 35 35
E20 20.0 2 24.1 39.6 42.3 40 45
E24 24.0 2 28.9 45.6 48.3 50 50
575 5.1 36.0 7.5 0.7 2.0 1.8 4.0
None-- -13.715.515 20
E09 9.0 1 8.7 18.3 20.6 20 25
E15 15.0 2 14.4 25.5 27.8 30 30
E20 20.0 2 19.2 31.6 33.8 35 35
E24 24.0 2 23.1 36.4 38.6 40 40
