York R-410A - Unit Dimensions PC090, PC120, YC090, YC;YD120, YC;YD150

505428-YTG-V-0417
92 Johnson Controls Unitary Products
Unit Dimensions PC090, PC120, YC090, YC/YD120, YC/YD150
Unit Height Dimensions
MODEL A
PC090 44.5
PC120 50.0
YC090 44.5
YC120 50.0
YD120 50.0
YC150 50.0
YD150 50.0
LEFT
REAR
RIGHT
FRONT
RIGHT
2X (Ø 0.875)
KNOCKOUT
30.994
2X (Ø 1.375)
KNOCKOUT
CONVENIENCE
OUTLET
7.00010.000
24.000
31.758
7.000
3.883
3.664
2.933
1.664
23.000
37.000
58.500
7.000
7.000
12.126
9.876
4.751
A
2X (Ø 1.375)
KNOCKOUT
REAR LEFT
2X (Ø 0.875)
KNOCKOUT
12.000
10.000
4.875
4.132
2.382
1.882
15.53
12.70
6.26
7.52
8.98
10.60
SYSTEM 2
SYSTEM 1
FRONT
31.90
59.10
BASE RAIL
DETAIL
2.923
3.563
2.375
3.75
3.43
TOP
BOTTOM
1.33
2.097
