Table 2 - Gasket/Caulk/Adhesive/Grommet for Solution Units
PART
NUMBER
DESCRIPTION WHERE USED
026-30458-000 Connector, Flex Fabric 8" Between fan opening and opening in panel
010-01017-010 Caulk, Sikafl ex, 221 SF, Sika Corp or Equal Corner connectors & raceway; inside corners where
corner connector, raceway and panels meet; wireway and
bulkhead seal
010-02917-000 Ins Therm 1/8 x 1-1/2 x 50 Lg, Ind. Rolls C3-
241-DC 221 White Ethafoam, W/psa, Std
R749 DTD 10/8/90 Marriage Tape
Coil seal, bulk head seal
013-02966-011 Caulk, Manus-bond,75-am, Manus Products,
or Equal
Corner connectors & raceway; inside corners where
corner connector, raceway and panels meet; wireway and
bulkhead seal
013-02976-010 Tape, Butyl, 0.75W x .19THK, TC-49 Xl 121,
Manus Products, or Equal
Outdoor units, between raceway 0.688 Flanges and
panels/ roof/drain pan/pipe chase/control enclosure,
panel to panel (vertical)
013-02977-010 Tape, Butyl, 1.5W x .13THK, TC-49 Xl 121,
Manus Products, or Equal
Outdoor units, between top raceways & along roof sides
& between bottom raceways & curb rest
013-02978-010 Tape, Butyl, 0.5W x .13THK, TC-49 Xl 121,
Manus Products, or Equal
Outdoor unit doors along sides when door is between two
panels
013-02979-010 Tape, Butyl, 0.5W x .25THK, TC-49 Xl 121,
Manus Products, or Equal
Outdoor units, between raceway 0.688 Flanges and roof
013-03317-010 Caulk, Solvent Free, Pace Gray or Equal,
Sikafl ex 221 SF or Manus-bond 75-AM
Corner connectors & raceway; inside corners where
corner connector, raceway and panels meet; wireway and
bulkhead seal
013-22013-010 Adhesive, Super Fast,#74, 3M or Equal Fan fl ex connection
028-11778-010 Gasket, Neoprene, Closed Cell, B/G, 1.25W x
0.25THK, Scott Mfg or Equal
Split, bottom, sides, top panel to panel ends butt to butt
028-11791-010 Gasket, Polyurethane, Open Cell, B/G, 1.0W x
1.0THK, Scott Mfg or Equal
Filters
028-11861-000 GROMMET, SUPPLY/RETURN
COIL HEADER, 1/8” PVC, For 3.00”
CONNECTIONS
Coil Header Panel, For 3.00” Connections
028-11861-000 GROMMET, SUPPLY/RETURN COIL
HEADER, 1/8” PVC
Coil Header Panel
01620 Gasket, Door, _____" High x _____" Wide Door (see example below)
028-11864-010 Gasket, Neoprene, Closed Cell, B/G, 0.75W x
0.5THK, Scott Mfg or Equal
Between vertical bulkheads and panel
028-11865-010 Foam, #2 Polyester, Open Cell, 2W x 2THK,
4LG, Scott Mfg or Equal
Wireway at pressure transitions.
028-11865-010 Gasket, Neoprene, Closed Cell, B/G, 1.0W x
2.0THK, Scott Mfg or Equal
Wireway at pressure transitions.
028-11866-001 Tape, Polyethylene, Double, 0.375W x
0.032THK, 5,184 In / Roll, or Equal
Between raceway double fl ange, between the liner
fl anges and out fl anges of panels
028-11866-002 Tape, Polyethylene, Double, 0.375W x
0.032THK, Spool, 60,000 In / Spool, or Equal
Between raceway double fl ange, between the liner
fl anges and out fl anges of panels
028-11866-010 Tape, Polyethylene, Double Sided, .38W x
0.13THK, Acrylic, Adhesive
Between raceway double fl ange, between the liner
fl anges and out fl anges of panels
028-11867-010 Gasket, Neoprene, Closed Cell, B/G, 1.25W x
.50THK, Scott Mfg or Equal
Between roof panels, type 8 fi lter tracks under the
bulkhead
Continued on next page
Example For Ordering Door Gasket:
Door is 35-1/2" High by 21-1/2" Wide
Order P/N 1620 35-1/2' High x 21-1/2" Wide.
