510667-YTG-B-0509
10 Johnson Controls Unitary Products
CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the
total electric power input during the same period.
— = Not Applicable.
ACCESSORIES
Refer to Price Manual for specific model numbers.
Start Assist Kit - Provides starting torque for low voltage appli-
cations.
Blower Time Delay - Available to increase efficiency when
installed. Installs on indoor section and maintains blower for
approximately one minute after cooling thermostat has been
satisfied.
Low Temperature Cutout (2LT06700224) - Prevents heat
pump operation below -1°F ambient temperature.
Thermal Expansion Valve Kit - 1TVM4 Series TXV kit used
when required.
Outdoor Thermostat (2TD06700124) - Provides additional
staging of supplemental electric heat.
Thermostats - Compatible thermostat controls are available
through accessory sourcing. For optimum performance and
installation, refer to the UPGNET “Low Voltage Wiring Diagram”
document to select and apply controls.
HEATING CAPACITY - With High Efficiency Motor Furnaces
UNIT
MODEL
VARIABLE SPEED
FURNACE MODEL
COIL
MODEL
1
HEATING
2
STAGE
RATED
CFM
NET MBH
HSPF COP @ 47
47 OD 17 OD
14.5 SEER HP WITH VARIABLE SPEED FURNACES
3
YHJF60S41S1
T*(8,L)X*C20 FC/MC62D
1 835 42.0 – – 2.98
2 1665 57.0 39.5 9.00 3.64
2 835 56.5 38.5 8.85 2.62
T*9X*C20 FC/MC62D
1 1220 43.5 – – 3.38
2 1595 57.0 40.0 9.00 3.58
2 1220 55.6 39.0 8.60 3.08
T*9X*D20 FC/MC62D
1 1240 43.5 – – 3.42
2 1645 57.0 40.0 9.00 3.60
2 1240 55.6 39.0 8.65 3.10
Y*(8,L)C*C20 FC/MC62D
1 1015 42.5 – – 3.20
2 1615 57.0 40.0 9.00 3.58
2 1015 55.6 39.0 8.75 2.86
(Y*9C/T*9V)*C20 FC/MC62D
1 1040 43.0 – – 3.20
2 1655 57.0 40.5 9.00 3.54
2 1040 54.9 39.0 8.70 2.88
(Y*9C/T*9V)*D20 FC/MC62D
1 1085 43.0 – – 3.26
2 1630 57.0 40.0 9.00 3.54
2 1085 55.6 39.0 8.65 2.94
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and no
supplemental electric heat operation.
3. Variable speed furnaces have B.O.D (Blower on Delay) standard.
