York SUNLINE DCE Series User Manual

290699-YIM-B-0607
26 Unitary Products Group
MODEL
TONNAGE
VOLTAGE
COMPRESSORS
OD FAN
MOTOR
FLA
ID
BLOWER
MOTOR
FLA
ELECTRIC HEATER
MODEL NO.
HEATER KW HEATER AMPS
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX. FUSE/
BRKR
1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
D(CE, CG)
060
(5.0)
208-3-60 16.0 125.0 1.3 5.2
None -- -- 26.5 35
2CE04510525
2
4 11.1 26.5 35
2CE04510725
2
5.6 15.5 26.5 35
2CE04511025 8 22.2 34.3 40
2CE04511525 11.9 33.0 47.8 50
2CE04512025 15.9 44.1 61.7 70
2CE04513025 22.2 61.6 83.5 90
230-3-60 16.0 125.0 1.3 5.2
None -- -- 26.5 35
2CE04510525
2
5.3 12.7 26.5 35
2CE04510725
2
7.5 18.0 29.1 40
2CE04511025 10.6 25.5 38.4 40
2CE04511525 15.9 38.2 54.3 60
2CE04512025 21.2 51.0 70.2 80
2CE04513025 29.6 71.2 95.5 100
460-3-60 8.0 66.5 0.8 2.6
None -- -- 13.4 20
2CE04510746
2
6.8 8.2 13.5 20
2CE04511046
2
10.1 12.1 18.4 20
2CE04511546
2
13.6 16.4 23.7 25
2CE04512046
2
19.5 23.5 32.6 35
2CE04513046
2
28.8 34.6 46.6 50
575-3-60 6.4 50.0 0.8 2.0
None -- -- 10.6 15
2CE04511058 10.6 10.2 15.2 20
2CE04511558 15.9 15.3 21.6 25
2CE04512058 21.2 20.4 28 30
2CE04513058 30.4 29.3 39.1 40
D(CE, CG)
072
(6.0)
208-3-60 18.9 146.0 1.3 5.0
None -- -- 29.9 40
2CE04510525
2
4 11.1 29.9 40
2CE04510725
2
5.6 15.5 29.9 40
2CE04511025 8 22.2 34 45
2CE04511525 11.9 33.0 47.5 50
2CE04512025 15.9 44.1 61.4 70
2CE04513025 22.2 61.6 83.3 90
230-3-60 18.9 146.0 1.3 5.0
None -- -- 29.9 40
2CE04510525
2
5.3 12.7 29.9 40
2CE04510725
2
7.5 18.0 29.9 40
2CE04511025 10.6 25.5 38.1 45
2CE04511525 15.9 38.2 54.1 60
2CE04512025 21.2 51.0 70 70
2CE04513025 29.6 71.2 95.3 100
460-3-60 9.5 73.0 0.8 2.5
None -- -- 15.2 20
2CE04510746
2
6.8 8.2 15.2 20
2CE04511046
2
10.1 12.1 18.3 20
2CE04511546
2
13.6 16.4 23.6 25
2CE04512046
2
19.5 23.5 32.4 35
2CE04513046
2
28.8 34.6 46.4 50
575-3-60 7.6 58.4 0.8 2.0
None -- -- 12.1 15
2CE04511058 10.6 10.2 15.2 20
2CE04511558 15.9 15.3 21.6 25
2CE04512058 21.2 20.4 28 30
2CE04513058 30.4 29.3 39.1 40
1.
HACR Type per NEC.
2.
These electric heaters do not include a fuse box. If a fuse box is required to meet a local code (i.e. Chicago), the fuse block
accessories 2FB04700825 and 2FB04700846 are available for field installation.
TABLE 14: ELECTRICAL DATA - D(CE, CG) 036-072 BELT DRIVE (CONT.)
