TABLE 5 - SUPPLY AIR BLOWER PERFORMANCE (7-1/2 - 12-1/2 TON)
BLOWER
SPEED,
RPM
CFM
2250 2550 3000 3400 3750
ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW
975 0.83 1.16 1.08 0.66 1.27 1.18 0.37 1.45 1.35 0.08 1.65 1.54 - - -
1025 0.98 1.21 1.13 0.82 1.34 1.25 0.52 1.54 1.44 0.21 1.75 1.63 - - -
1070 1.12 1.32 1.23 0.95 1.46 1.36 0.67 1.68 1.57 0.37 1.89 1.76 0.07 2.11 1.97
1130 1.31 1.43 1.33 1.16 1.57 1.46 0.86 1.83 1.71 0.56 2.04 1.90 - - -
1175 1.51 1.51 1.41 1.36 1.67 1.56 1.07 1.92 1.79 0.75 2.18 2.03 - - -
1220 1.68 1.66 1.55 1.53 1.81 1.69 1.23 2.10 1.96 - - - - - -
MODEL DEG090 - (SIDE DUCT APPLICATIONS)
BLOWER
SPEED,
RPM
CFM
2250 2550 3000 3400 3750
ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW
975 0.761.161.080.571.271.180.241.451.35------
1025 0.91 1.21 1.13 0.73 1.34 1.25 0.39 1.54 1.44 0.04 1.75 1.63 - - -
1070 1.05 1.32 1.23 0.86 1.46 1.36 0.54 1.68 1.57 0.20 1.89 1.76 - - -
1130 1.24 1.43 1.33 1.07 1.57 1.46 0.73 1.83 1.71 0.39 2.04 1.90 - - -
1175 1.44 1.51 1.41 1.27 1.67 1.56 0.94 1.92 1.79 0.58 2.18 2.03 - - -
1220 1.61 1.66 1.55 1.44 1.81 1.69 1.10 2.10 1.96 ------
MODEL DEG090 - (BOTTOM DUCT APPLICATIONS)
BLOWER
SPEED,
RPM
CFM
3000 3500 4000 4500 5000
ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW
860 1.05 1.40 1.31 0.85 1.58 1.48 0.62 1.80 1.68 0.32 2.05 1.91 - - -
915 1.23 1.55 1.45 1.05 1.76 1.64 0.80 1.98 1.85 0.51 2.23 2.08 0.22 2.48 2.31
950 1.42 1.68 1.57 1.24 1.91 1.78 1.00 2.14 2.00 0.70 2.43 2.27 0.40 2.72 2.54
1000 1.60 1.83 1.71 1.44 2.07 1.93 1.20 2.33 2.17 0.93 2.62 2.45 0.65 2.91 2.72
1050 1.80 1.98 1.84 1.65 2.25 2.10 1.42 2.55 2.37 1.14 2.86 2.67 0.85 3.17 2.96
1090 1.99 2.12 1.97 1.84 2.41 2.24 1.63 2.72 2.54 1.34 3.06 2.86 - - -
MODEL DEG120 - (SIDE DUCT APPLICATIONS)
BLOWER
SPEED,
RPM
CFM
3000 3500 4000 4500 5000
ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW
860 0.92 1.40 1.31 0.67 1.58 1.48 0.39 1.80 1.68 0.02 2.05 1.91 - - -
915 1.10 1.55 1.45 0.87 1.76 1.64 0.57 1.98 1.85 0.21 2.23 2.08 - - -
950 1.29 1.68 1.57 1.06 1.91 1.78 0.77 2.14 2.00 0.40 2.43 2.27 0.04 2.72 2.54
1000 1.47 1.83 1.71 1.26 2.07 1.93 0.97 2.33 2.17 0.63 2.62 2.45 0.29 2.91 2.72
1050 1.67 1.98 1.84 1.47 2.25 2.10 1.19 2.55 2.37 0.84 2.86 2.67 0.49 3.17 2.96
1090 1.86 2.12 1.97 1.66 2.41 2.24 1.40 2.72 2.54 1.04 3.06 2.86 - - -
MODEL DEG120 - (BOTTOM DUCT APPLICATIONS)
BLOWER
SPEED,
RPM
CFM
4000 4500 5000 5500 6000
ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW
960 1.00 2.14 2.00 0.70 2.43 2.27 0.40 2.72 2.54 0.11 3.03 2.83 - - -
1000 1.20 2.33 2.17 0.93 2.62 2.45 0.65 2.91 2.72 0.35 3.24 3.03 0.16 4.20 3.91
1050 1.42 2.55 2.37 1.14 2.86 2.67 0.85 3.17 2.96 0.62 4.06 3.79 0.39 4.53 4.22
1090 1.63 2.72 2.54 1.34 3.06 2.86 1.10 3.78 3.53 0.78 4.28 3.99 0.58 4.79 4.46
1105 1.74 3.08 2.87 1.47 3.45 3.22 1.18 3.88 3.62 0.85 4.35 4.06 0.66 4.89 4.56
1140 1.91 3.25 3.03 1.63 3.66 3.41 1.35 4.11 3.83 1.02 4.53 4.22 0.85 5.12 4.77
MODEL DEG150 - (SIDE DUCT APPLICATIONS)
BLOWER
SPEED,
RPM
CFM
4000 4500 5000 5500 6000
ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW ESP BHP KW
960 0.772.142.000.402.432.270.042.722.54------
1000 0.97 2.33 2.17 0.63 2.62 2.45 0.29 2.91 2.72 ------
1050 1.19 2.55 2.37 0.84 2.86 2.67 0.49 3.17 2.96 0.26 4.06 3.79 - - -
1090 1.40 2.72 2.54 1.04 3.06 2.86 0.74 3.78 3.53 0.42 4.28 3.99 0.18 4.79 4.46
1105 1.51 3.08 2.87 1.17 3.45 3.22 0.82 3.88 3.62 0.49 4.35 4.06 0.26 4.89 4.56
1140 1.68 3.25 3.03 1.33 3.66 3.41 0.99 4.11 3.83 0.66 4.53 4.22 0.45 5.12 4.77
NOTES: Blower performance includes a wet evaporator coil, 2" filters and the maximum number of heat exchangers.
Refer to Table 6 for the resistance of the unit accessories.
ESP = External Static Pressure available for the supply and return air duct sytem. All internal unit
resistances have been deducted from the total static pressure of the blower.
MODEL DEG150 - (BOTTOM DUCT APPLICATIONS)
= Larger Horsepower Alternate Motor Required.
530.22-N4Y
10 Unitary Products Group
