York THGD30 - Page 13

365147-YTG-C-0608
Johnson Controls Unitary Products 13
HEATING CAPACITY - With Variable Speed Furnaces
UNIT
MODEL
VARIABLE
SPEED
FURNACE
COIL
1
MODEL
ARI HEATING
2
47°F17°FHSPF
MBH COP KW MBH COP KW STD
13 SEER HP WITH VARIABLE SPEED FURNACES
3
THGD18S21S1
PV8*A12 FC/MC/PC/UC18A 17.0 3.46 1.41 9.0 2.32 1.09 8.00
PV9*A12 FC/MC/PC/UC18A 17.0 3.42 1.43 9.0 2.28 1.13 8.00
P(C,V)9*B12 FC/MC/PC/UC18B 17.0 3.46 1.41 9.0 2.30 1.10 8.00
PV8*A12 FC/MC/PC/UC24A 17.0 3.46 1.41 9.0 2.32 1.09 8.00
PV9*A12 FC/MC/PC/UC24A 17.0 3.42 1.43 9.0 2.28 1.13 8.00
P(C,V)9*B12 FC/MC/PC/UC24B 17.0 3.46 1.41 9.0 2.30 1.10 8.00
PV8*A12 FC/MC/PC/UC30A 17.0 3.46 1.41 9.0 2.32 1.09 8.00
PV9*A12 FC/MC/PC/UC30A 17.0 3.42 1.43 9.0 2.28 1.13 8.00
P(C,V)9*B12 FC/MC/PC/UC30B 17.0 3.46 1.41 9.0 2.30 1.10 8.00
PV8*A12 HC18 17.0 3.46 1.41 9.0 2.32 1.09 8.00
PV9*A12 HC18 17.0 3.42 1.43 9.0 2.28 1.13 8.00
THGD24S21S1
PV8*A12 FC/MC/PC/UC24A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV9*A12 FC/MC/PC/UC24A 23.0 3.92 1.68 12.0 2.58 1.34 8.00
P(C,V)9*B12 FC/MC/PC/UC24B 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV8*A12 FC/MC/PC/UC30A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV9*A12 FC/MC/PC/UC30A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
P(C,V)9*B12 FC/MC/PC/UC30B 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV8*A12 FC/MC/PC/UC32A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV9*A12 FC/MC/PC/UC32A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
P(C,V)9*B12 FC/MC/PC/UC35B 23.0 3.96 1.67 12.0 2.58 1.34 8.00
PV8*A12 HC30 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV9*A12 HC30 23.0 3.94 1.68 12.0 2.58 1.34 8.00
P(C,V)9*B12 HC36 23.0 3.96 1.67 12.0 2.58 1.34 8.00
THGD30S21S1
PV8*A12 FC/MC/PC/UC32A 29.0 3.68 2.29 15.0 2.30 1.85 7.85
PV9*A12 FC/MC/PC/UC32A 29.0 3.66 2.30 15.0 2.30 1.85 7.80
PV8*B16 FC/MC/PC/UC35B 28.0 3.76 2.21 14.0 2.36 1.77 7.95
PV8*C16 FC/MC/PC/UC35C 28.0 3.78 2.20 14.0 2.36 1.77 7.95
PV8*C20 FC/MC/PC/UC35C 29.0 3.66 2.30 15.0 2.30 1.87 7.85
P(C,V)9*B12 FC/MC/PC/UC35B 29.0 3.70 2.26 14.0 2.32 1.83 7.85
P(C,V)9*C16 FC/MC/PC/UC35C 29.0 3.74 2.24 14.0 2.34 1.80 7.90
PV8*A12 FC/MC/PC/UC37A 29.0 3.66 2.30 15.0 2.30 1.85 7.80
PV9*A12 FC/MC/PC/UC37A 29.0 3.66 2.30 15.0 2.30 1.85 7.80
PV8*B16 FC/MC/PC/UC43B 28.0 3.76 2.21 14.0 2.36 1.77 7.95
PV8*C16 FC/MC/PC/UC43C 28.0 3.78 2.20 14.0 2.38 1.76 8.00
PV8*C20 FC/MC/PC/UC43C 29.0 3.68 2.29 15.0 2.30 1.85 7.85
P(C,V)9*B12 FC/MC/PC/UC43B 29.0 3.72 2.25 14.0 2.34 1.81 7.90
P(C,V)9*C16 FC/MC/PC/UC43C 29.0 3.74 2.24 14.0 2.34 1.80 7.90
PV8*B16 HC36 28.0 3.76 2.21 14.0 2.36 1.77 7.95
P(C,V)9*B12 HC36 29.0 3.70 2.26 14.0 2.32 1.83 7.85
PV8*C16 HC42 28.0 3.78 2.20 14.0 2.38 1.76 8.00
PV8*C20 HC42 29.0 3.68 2.29 15.0 2.32 1.84 7.85
P(C,V)9*C16 HC42 29.0 3.74 2.24 14.0 2.34 1.80 7.90
For Notes See Page 14.
