York THGD30 - Page 14

365147-YTG-C-0608
14 Johnson Controls Unitary Products
CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by
the total electric power input during the same period.
— = Not Applicable.
THGD36S21S1
PV8*A12 FC/MC/PC/UC37A 34.0 3.66 2.68 20.0 2.56 2.31 8.65
PV9*A12 FC/MC/PC/UC37A 34.0 3.60 2.76 20.0 2.54 2.35 8.55
PV8*B16 FC/MC/PC/UC43B 33.0 3.74 2.61 20.0 2.62 2.23 8.80
PV8*C16 FC/MC/PC/UC43C 33.0 3.76 2.60 20.0 2.64 2.21 8.85
PV8*C20 FC/MC/PC/UC43C 33.0 3.70 2.64 20.0 2.60 2.25 8.75
P(C,V)9*B12 FC/MC/PC/UC43B 34.0 3.68 2.67 20.0 2.58 2.29 8.70
P(C,V)9*C16 FC/MC/PC/UC43C 33.0 3.74 2.61 20.0 2.62 2.23 8.80
P(C,V)9*C20 FC/MC/PC/UC43C 33.0 3.74 2.61 20.0 2.62 2.23 8.80
PV8*C16 FC/MC/PC/UC48C 33.0 3.78 2.57 20.0 2.66 2.19 8.90
PV8*C20 FC/MC/PC/UC48C 33.0 3.72 2.63 20.0 2.60 2.25 8.75
P(C,V)9*C16 FC/MC/PC/UC48C 33.0 3.76 2.60 20.0 2.64 2.21 8.85
P(C,V)9*C20 FC/MC/PC/UC48C 33.0 3.76 2.60 20.0 2.64 2.21 8.85
P(C,V)9*D20 FC/MC/PC/UC48D 33.0 3.76 2.60 20.0 2.64 2.21 8.85
PV8*C16 HC42 33.0 3.76 2.58 20.0 2.64 2.21 8.85
PV8*C20 HC42 33.0 3.72 2.63 20.0 2.60 2.25 8.75
P(C,V)9*C16 HC42 33.0 3.74 2.61 20.0 2.62 2.23 8.80
P(C,V)9*C20 HC42 33.0 3.76 2.60 20.0 2.64 2.21 8.85
THGD42S21S1
PV8*C16 FC/MC/PC/UC48C 41.0 3.62 3.31 25.0 2.68 2.68 8.70
PV8*C20 FC/MC/PC/UC48C 41.0 3.64 3.30 24.0 2.70 2.64 8.75
P(C,V)9*C16 FC/MC/PC/UC48C 41.0 3.60 3.33 25.0 2.66 2.70 8.65
P(C,V)9*C20 FC/MC/PC/UC48C 41.0 3.62 3.31 25.0 2.68 2.68 8.70
P(C,V)9*D20 FC/MC/PC/UC48D 41.0 3.60 3.33 25.0 2.68 2.68 8.70
PV8*C16 FC/PC/UC60C 41.0 3.62 3.31 24.0 2.68 2.66 8.70
PV8*C20 FC/PC/UC60C 41.0 3.64 3.30 24.0 2.70 2.64 8.75
P(C,V)9*C16 FC/PC/UC60C 41.0 3.60 3.33 25.0 2.66 2.70 8.65
P(C,V)9*C20 FC/PC/UC60C 41.0 3.62 3.31 24.0 2.68 2.66 8.70
P(C,V)9*D20 FC/MC/PC/UC60D 41.0 3.62 3.31 25.0 2.68 2.68 8.70
THGD48S21S1
PV8*C16 FC/PC/UC60C 48.0 3.42 4.06 37.0 2.76 3.92 7.80
PV8*C20 FC/PC/UC60C 48.0 3.44 4.04 37.0 2.78 3.92 8.00
P(C,V)9*C16 FC/PC/UC60C 47.0 3.40 4.05 37.0 2.76 3.97 7.80
P(C,V)9*C20 FC/PC/UC60C 48.0 3.42 4.06 37.0 2.76 3.94 8.00
P(C,V)9*D20 FC/MC/PC/UC60D 48.0 3.44 4.04 37.0 2.78 3.92 8.00
PV8*C20 FC/MC62D 48.0 3.44 4.04 37.0 2.78 3.92 8.00
P(C,V)9*C20 FC/MC62D 48.0 3.42 4.06 37.0 2.76 3.94 8.00
P(C,V)9*D20 FC/MC62D 48.0 3.44 4.04 37.0 2.78 3.92 8.00
THGD60S21S1
PV8*C20 FC/MC62D 58.0 3.48 4.84 39.0 2.38 4.80 7.70
P(C,V)9*C20 FC/MC62D 57.0 3.48 4.79 38.0 2.38 4.73 7.70
P(C,V)9*D20 FC/MC62D 56.0 3.50 4.68 38.0 2.38 4.73 7.75
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and
no supplemental electric heat operation.
3. Variable speed furnaces have B.O.D (Blower on Delay) standard.
HEATING CAPACITY - With Variable Speed Furnaces (Continued)
UNIT
MODEL
VARIABLE
SPEED
FURNACE
COIL
1
MODEL
ARI HEATING
2
47°F17°FHSPF
MBH COP KW MBH COP KW STD
