York Y34 - Component Location

246653-YTG-E-0108
80 Johnson Controls Unitary Products
FIGURE 28 - COMPONENT LOCATION
FILTER ACCESS
EVAPORATOR COIL
AND DRAINPAN ACCESS
POWER & CONTROL WIRING
COMPRESSOR ACCESS
HEAT SECTION
POWER EXHAUST ACCESS
FILTER ACCESS
EVAPORATOR COIL
AND DRAINPAN ACCESS
HEAT SECTION
SUPPLY BLOWER & MOTOR
FILTER DRIERS
RIGHT
SIDE
LEFT SIDE
FRONT
REAR
REAR
