SECTION 3 – SYSTEM COMPONENTS DESCRIPTION
OIL PUMP
For normal operation, the oil pump should operate at
all times during chiller operation.
On shutdown of the system for any reason, the oil
pump operates and continues to run for 150 seconds.
The system cannot restart during that time interval.
FIGURE 5 - SYSTEM COMPONENTS
LD08634
COMPRESSOR 1
COMPRESSOR 2
MOTOR 1
MOTOR 2
EVAPORATOR
CONDENSER
CONTROL
CENTER
