JOHNSON CONTROLS
140
FORM 150.72-ICOM6
ISSUE DATE: 08/03/2022
SECTION 7 – UNIT CONTROLS
S Y S X L L S V I S X X X
H O T G A S S O L I S X X X
Displays whether the System Liquid Line Solenoid or
Hot Gas Solenoid was energized at the time of the fault.
S Y S X F A N S T A G E X X X
Displays the number of Fan Stages in the system active
at the time of the fault.
S Y S X A C T U A L A M P S
= X X X . X A M P S
Software Version
The software version may be viewed by first pressing
(DOWN) arrow key until you scroll past the first his-
tory buffer choice.
D I S P L A Y S A F E T Y S H U T -
D O W N N O . 1 ( 1 T O 6 )
software version will appear.
C O N T R O L C. M X X. Z Z. Y Y
I / O C. M X X. 1 8. Y Y
