York ZF150 - ZF078-150 Unit Electrical Entry; ZF078-120 Unit Side Duct Openings

518674-YIM-C-0610
Johnson Controls Unitary Products 13
Figure 11: ZF078-150 Unit Electrical Entry
Figure 12: ZF078-120 Unit Side Duct Openings
Disconnect Swith Cover
Power Entry Ø 2-1/2
Control Entry Ø 7/8
Power Entry Ø 2-1/2
Convenience Outlet Cover
Convenience Outlet
Power Entry Ø 7/8
FRONT
Dot Plugs
5-5/32
31-11/16
2-31/32
18-1/4
Return
Air
Supply
Air
A
B
C
D
