York ZW-06 User Manual

5803642-TIM-B-0620
20 Johnson Controls Ducted Systems
Table 9: Electrical Data
ZWTA3 thru TA5 Standard Indoor Blower - Without Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
MCA
1
w/Pwr
Exh
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
TA3
(3)
208 9.2 70 13 2.1 5.2 5.5
None-- -18.824.325 30
E03 2.3 1 6.4 18.8 24.3 25 30
E06 4.5 1 12.5 22.1 29 25 30
E08 6.8 1 18.9 30.1 37 35 40
E15 11.3 2 31.4 45.8 52.6 50 60
230 9.2 70 13 2.1 5.2 5.5
None-- -18.824.325 30
E03 3 1 7.2 18.8 24.3 25 30
E06 6 1 14.4 24.5 31.4 25 35
E08 9 1 21.7 33.6 40.5 35 45
E15 15 2 36.1 51.6 58.5 60 60
460 4 31 6 1.26 2.6 2.2
None - - - 8.9 11.1 15 15
E03 3 1 3.6 8.9 11.1 15 15
E06 6 1 7.2 12.3 15 15 15
E08 9 1 10.8 16.8 19.5 20 20
E15 15 2 18 25.8 28.5 30 30
575 3.5 27 5 0.66 2 1.8
None - - - 7.1 8.9 15 15
E08 9 1 8.7 13.4 15.6 15 20
E15 15 2 14.4 20.5 22.8 25 25
TA4
(4)
208 13.8 83.1 22 2.1 5.2 5.5
None-- -24.630.135 40
E06 4.5 1 12.5 24.6 30.1 35 40
E08 6.8 1 18.9 30.1 37 35 40
E15 11.3 2 31.4 45.8 52.6 50 60
E20 15 2 41.6 58.5 65.4 60 70
230 13.8 83.1 22 2.1 5.2 5.5
None-- -24.630.135 40
E06 6 1 14.4 24.6 31.4 35 40
E08 9 1 21.7 33.6 40.5 35 45
E15 15 2 36.1 51.6 58.5 60 60
E20 20 2 48.1 66.6 73.5 70 80
460 6.2 41 10 1.26 2.6 2.2
None-- -11.713.915 20
E06 6 1 7.2 12.3 15 15 20
E08 9 1 10.8 16.8 19.5 20 20
E15 15 2 18 25.8 28.5 30 30
E20 20 2 24.1 33.4 36.1 35 40
575 4.9 33 8 0.66 2 1.8
None - - - 8.8 10.6 15 15
E08 9 1 8.7 13.4 15.6 15 20
E15 15 2 14.4 20.5 22.8 25 25
E20 20 2 19.2 26.5 28.8 30 30
TA5
(5)
208 12.4 93 19 2.1 5.2 5.5
None-- -24.930.435 40
E06 4.5 1 12.5 24.9 30.4 35 40
E08 6.8 1 18.9 30.1 37 35 40
E15 11.3 2 31.4 45.8 52.6 50 60
E20 15 2 41.6 58.5 65.4 60 70
E23 18 2 50 69 75.9 70 80
230 12.4 93 19 2.1 5.2 5.5
None-- -24.930.435 40
E06 6 1 14.4 24.9 31.4 35 40
E08 9 1 21.7 33.6 40.5 35 45
E15 15 2 36.1 51.6 58.5 60 60
E20 20 2 48.1 66.6 73.5 70 80
E23 24 2 57.7 78.6 85.5 80 90
460 6 60 9 1.26 2.6 2.2
None-- -12.614.815 20
E06 6 1 7.2 12.6 15 15 20
E08 9 1 10.8 16.8 19.5 20 20
E15 15 2 18 25.8 28.5 30 30
E20 20 2 24.1 33.4 36.1 35 40
E23 24 2 28.9 39.4 42.1 40 45
575 4.7 41 7 0.66 2 1.8
None - - - 9.2 11 15 15
E08 9 1 8.7 13.4 15.6 15 20
E15 15 2 14.4 20.5 22.8 25 25
E20 20 2 19.2 26.5 28.8 30 30
E23 24 2 23.1 31.4 33.6 35 35
