Attach one stabiliser to each corner of the tower as shown. Ensure
stabiliser feet are equally spaced to form a square.
SP10 and SP15 telescopic stabilisers must always be fully
extended.
Position the lower clamp so that the lower arm is as close to the
horizontal as possible. Adjust the position of the top clamp to
ensure the stabiliser foot is in firm contact with the ground. Ensure
clamps are secure.
Stabilisers are used when the tower is to be moved occasionally,
frequent movement will require mobile outriggers.
When moving the tower, adjust the top clamps to lift the four
stabiliser feet a maximum of 25mm off the ground and then
unlock the castor brakes. After moving ensure all four stabiliser
feet are repositioned in firm contact with the ground.
For information on mobile outriggers please consult your supplier.
Stabilisers and Outriggers
Mobile Towers - 3T Method
STABILISERS
30
OUTRIGGERS
Max Extension
y
STABILISER DIMENSIONS
y
SP7 1227
SP10 2241
SP15 2757
For further information about
this product or any other
products and services,
please contact :
Youngman Group Ltd
The Causeway, Maldon,
Essex, CM9 4LJ,
United Kingdom
t +44 (0)1621 745900
f +44 (0)1621 859845
e sales@youngmangroup.com
youngmangroup.com
Part No: 032994 Date: 05/10
