Safety First
Horizontal
Brace
4 Rung
Frame
Side
Toeboard
Platform
(Fixed and
Trapdoor Decks)
Diagonal
Brace
4 Rung Ladder Frame
End Toeboard
Stabiliser
2 Rung
Frame
Castor
Adjustable Leg
2 Rung Ladder Frame
BoSS 1450 Ladderspan to EN 1004: Available in 2 lengths - 1.8m and 2.5m
Internal/External Use - Towers under 2.5m are outside of the scope of EN1004 Internal Use
COMPONENT WORKING HEIGHT (m)
PLATFORM HEIGHT (m)
3.2
1.2
3.7
1.7
4.2
2.2
4.7
2.7
5.2
3.2
5.7
3.7
6.2
4.2
6.7
4.7
7.2
5.2
7.7
5.7
8.2
6.2
8.7
6.7
9.2
7.2
9.7
7.7
10.2
8.2
10.7
8.7
11.2
9.2
11.7
9.7
12.2
10.2
12.7
10.7
13.2
11.2
13.7
11.7
14.2
12.2
125/150/200mm Castor 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
Adjustable leg assembly 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
1450 2 Rung Ladder Frame 1 1 1 1 1 1 1 1 1 1 1 1
1450 2 Rung Span Frame 1 1 1 1 1 1 1 1 1 1 1 1
1450 3 Rung Ladder Frame 1 1 1 1 1 1 1 1 1 1 1
1450 3 Rung Span Frame 1 1 1 1 1 1 1 1 1 1 1
1450 4 Rung Ladder Frame 1 1 1 2 1 2 2 3 2 3 3 4 3 4 4 5 4 5 5 6 5 6
1450 4 Rung Span Frame 1 1 1 2 1 2 2 3 2 3 3 4 3 4 4 5 4 5 5 6 5 6
1.8m and 2.5m Fixed Deck 1 1 1* 2 1 1 1 2 1 1 1 2 1 1 1 2 1 1 1 2 1 1 1
1.8m and 2.5m Trap Door Deck 1 1 1 1 2 2 2 2 3 3 3 3 4 4 4 4 5 5 5 5 6 6 6
1.8m and 2.5m Horizontal Brace (red) 6 6 6 6 10 10 10 10 14 14 14 14 18 18 18 18 22 22 22 22 26 26 26
2.1m and 2.7m Diagonal Brace (blue) 2 3 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
IMPORTANT: Please ensure you also read the Quantity Schedule on page 8.
* If you are unable to position the working platform easily from the ground, you may require an additional fixed platform for this tower
height.
Quantity Schedule
1450 Width Towers
7 8
Quantity Schedule
1450 Width Towers
BoSS 1450 Ladderspan to EN 1004: Available in 2 lengths - 1.8m and 2.5m
Internal/External Use Internal Use
COMPONENT WORKING HEIGHT (m)
PLATFORM HEIGHT (m)
3.2
1.2
3.7
1.7
4.2
2.2
4.7
2.7
5.2
3.2
5.7
3.7
6.2
4.2
6.7
4.7
7.2
5.2
7.7
5.7
8.2
6.2
8.7
6.7
9.2
7.2
9.7
7.7
10.2
8.2
10.7
8.7
11.2
9.2
11.7
9.7
12.2
10.2
12.7
10.7
13.2
11.2
13.7
11.7
14.2
12.2
1.8m and 2.5m Side Toeboard 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
1.2m End Toeboard 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Toeboard Holder 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
SP7 Fixed Stabiliser 4 4 4 4 4 4
SP10 Telescopic Stabiliser 4 4 4 4 4 4 4 4 4 4 4 4 4
SP15 Telescopic Stabiliser 4
1.8m TOWER Total Self-weight (kgs)
91 99 103 146 161 169 175 195 210 231 237 257 272 279 300 306 320 328 334 354 369 377 383
2.5m TOWER Total Self-weight (kgs)
108 116 143 169 185 194 201 226 243 264 271 296 313 321 343 354 370 378 385 411 427 436 443
See pages 10 and 30 for stabiliser positions.
