YTL YARD COMMANDER User Manual

15
Ref# Drawing No. Description Qty
1
N570-00012-000
Handle Spacer 1
2
9114-06025-DG
Carriage Bolt M6x25 1
3
9315-08000-DG Teeth Washer Ø8
1
4
N570-10000-000
Gauge & Lever Assembly 1
5
N570-00001-000
Adjust Handle Pole 1
6
N570-00014-000
Adjust Handle A 1
7
N570-00015-000
Adjust Handle B 1
8
9199-04018-DG
Screw ST4.2x18 1
9
N510-00016-000
Spacer 1
10
N510-00019-000
Wing Nut M6 1
11
9101-06045-DG
Hex Bolt M6x45 5
12
C130-00004-000
Nylon Washer 1
13
9302-06000-DG
Flat Washer Ø6 1
14
N570-00016-000
Screen 1
15
N570-00009-000
Handle Cover 2
16
N570-00013-000
Hopper 1
17
N578-00001-000
R Pin 1
18
N570-00019-000
Hopper Bushing 1
19
N570-30000-000
Pivot & Bracket Assembly 1
20 N570-00007-000 Wheel Assembly Frame 2
21
9201-06000-DG
Hex Nut M6 2
22
T680-00003-000
End Cover 2
23
N570-00006-000
Handle 2
24
9206-06000-DG
Lock Nut M6 12
25
N570-00003-000
Control Rod A 1
26
N570-00005-000
Handle Shaft 1
27
N510-00023-000
Shut off plate 1
28
9302-04000-DG
Flat Washer Ø4 3
29
9199-04012-DG
Screw ST4.2x12 3
30
N570-00008-000
Frame 1
31
N570-00010-000
Frame Brace 2
32
9101-06060-DG
Hex Bolt M6X60 2
33
9101-06035-DG
Hex Bolt M6X35 4
34
9301-16000-DG
Flat Washer Ø16 1
35
N511-40000-000
End Cap 2
36
N570-00020-000
Pneumatic Wheel 2
37
N570-00018-000
Inner Axle Bushing 2
38
N570-00011-000
Outer Axle Bushing 2
Parts List
