Ref# Drawing No. Description Qty
39
N578-01000-000
Gear Box & Axle Assemble 1
40
N570-00002-000
Thin Washer 1
41
9199-04020-DG
Screw M4x20 1
42
N510-00003-000
Impeller 1
43
9199-06040-DG
Screw ST6.3X40 4
44
9206-05000-DG
Hex Lock Nut M5 1
45
N570-00021-000
Cross Brace 1
46
N570-00004-000
Adjust Connect Rod B 1
47
9101-05045-DG
Hex Bolt M5X45 1
48
9301-06000-DG
Flat Washer Ø6 3
49
N570-00022-000
Rain Cover 1
50
9306-06000-DG
Lock Washer Ø6 1
51
9404-02010-DG
Cotter Pin Ø2x10 1
52
N570-00027
Nylon Washer 4
