11
Cylinder compression clearance
(mm)
1±O.1
Oil volume (L)
13(11 in oil sump)
Tightening torques of the connecting screw thread
1. Tightening torques of main bolts and nuts are shown below:
Description
Tightening torque(N•m)
Description
Tightening torque(N•m)
Cylinder head
bolt
210~250
Flywheel bolt
170~210
Main bearing
bolt
220~260
Crankshaft belt
pulleyfastening bolt
≥300
Connecting
rod bolt
160~200
Camshaft gear locking
bolt
≥300
2.Except for the important connecting screw thread, tightening torque of other bolts and
nuts can be selected according to the table below:
Screw thread
specifications
M6
M8
MlO
M12
M14
Tightening
torque(N·m)
10~20
20~30
35~55
70~90
110~130
