Yudian AI Series User Manual

15
OP1 output type
OP1 select the control output type:
OP1=OP1.A x 1 + OP1.B x 10
OP1.A shows the output type of OUTP. It should be compatible w
ith the
module installed in OUTP sockets.
OP1.A=0,
if output modules such as SSR voltage output, relay contact
discrete output, thyristor cross zero trigger output, and TRIAC no-contact
discrete output are installed in OUTP.
OP1.A=1, 0～10mA linear curren
t output. Linear current output module
should be installed to main output.
OP1.A=2, 0～
20mA linear current output. Linear current output module
should be installed to main output.
OP1.A=3, spare
OP1.A=4, 4~20mA linear current output. Linear current output module
should be installed to main output.
OP1.A=5～7, is for other models, please not use it for AI-518/518P.
OP1.A=8, single channel phase-
shift output. K5 module should be
installed. AUX can not work as refrigerating output.
OP1.B shows the AUX output type. It works only when parameter oPL<0.
OP1.B=0, time proportional output.
Output modules such as SSR
voltage output, relay contact discrete output, thyristor cross zero trigger output,
and TRIAC no-contact discrete output can be installed in OUTP.
OP1.B=1, 0～
10mA linear current output. Linear current output module
should be installed to main output.
OP1.B=2, 0～
20mA linear current output. Linear current output module
should be installed to main output.
OP1.B=3, spare
OP1.B=4, 4～20mA linear current output.
Linear current output module
should be installed to main output.
AUX does not support position proportional output or phase-
shift trigger
output.
For example, OUT and AUX all output 4～
20mA linear current, then
OP=44.
0～48
OPL Output low limit
0
～
110%: OPL is the minimum output of OUTP in single directional control
system.
-110 ～ -
1%: the instrument works for a bidirectional system, and has
heating/refrigerating dual output. When CF.A=0, OUTP (main output) works
for heating, and AUX (Auxiliary output) works for refrigerating. When CF.A=1,
OUTP works for refrigerating, and AUX works for heating.
In a bidirectional system, the heating and refrigerating ability are generally
different.
OPL = -
(power when AUX output is maximum /power when OUTP output is
maximum) x 100%.
For example, for a heating/refrigerating air condition, its maximum power of
refrigerating is 4000W, and maximum power of heating is 5000W, and AUX
works for refrigerating, then
OPL=- (4000/5000)x100% = -80%
The range of AUX output can’t be fre
ely defined by user. If the internal
calculation requires maximum output of AUX (AUX output=OPL), then in 4～
20mA output, the AUX output is 20mA, and user can’t limit the maximum AUX
output to 10mA.
-110～
+110%
OPH
Output upper
limit
OPL limits the maximum of OUTP (main output). OPH should be greater than
OPL.
0～110%

Yudian AI Series Specifications

General

Control Mode	On/Off
Input Type	Thermocouple (K, S, T, E, J, B, N), RTD (Pt100, Cu50), Linear Current (4-20mA), Linear Voltage (0-5V, 1-5V)
Output Type	Relay, SSR, Linear Current (4-20mA)
Power Supply	AC 90-260V, 50/60Hz or DC 24V
Communication	RS485 Modbus RTU
Accuracy	±0.2%FS
Operating Temperature	0-50°C
Storage Temperature	-20-60°C
Humidity	85% RH (non-condensing)
Protection	IP65 (Front Panel)
