Yuwell YE620B - Product Structure and Parts

05
04
SYS
mmHg
DIA
mmHg
P/min
Product structure and parts
1. Main part
Product structure and parts
Warning:
otherwise the measurement results will be
inaccurate.
Please use cuff made by Yuwell,
Display
Memory button
Start/Stop button
Plug port
3. AC adapter and USB cable
INPUT: 100-240V~
50/60Hz 0.35A MAX
OUTPUT: 5V 1000mA
MFR: WEIHAI HITAI ELECTRONICS Co.,LTD.
EU Model: HT-C38B-0510EW
US Model: HT-C38B-0510WW
UK Model: HT-C38B-0510UW
AC adapter:
AC adapter
(optional)
USB cable
(optional)
2. Cuff
There are 6 types of cuff provided by yuwell.
Please subject to the received type.
Rubber air tube
Cuff
Air plug
22~45cm
2~3cm
Please select a suitable size cuff according to the
arm circumference. Out of the given value can lead
to inaccurate results of measurements.
Model
Charac-
eristict
The range
of arm
circumfe-
rence
YE-61MC YE-61LC
YE-62MC
YE-62LC YE-63MC YE-63LC
With hard support
Without hard support
Fabric: 210T polyester Fabric 250D polyester:
22cm
-
32cm
22cm
-
45cm
22cm
-
32cm
22cm
-
45cm
22cm
-
32cm
22cm
-
45cm
4. Display
5. Accessories
User's manual，Warranty card，4 AA batteries，
AC adapter(optional)，USB cable(optional)
Power adapter socket
Battery cover
SYS(systolic)
DIA(diastolic)
Pulse rate
Inflation&Deflation icon
Record icon
Record number
Time and date
Unit display
Detection icon for
cuff wearing
Indication icon for movement error
Battery power
icon
Heartbeat icon
Indication icon for
irregular heartbeats
D
I
A
m
m
H
g
P/
mi
n
SYS
m
mHg
