3
WWW.ZALMAN.COM
5. Installation
Connect the extension fan cable to the fan connector of cooler.
①
Install the Intel clip to the base of cooler using the bolts (Clip).
Please make sure to put the curved part of clip toward the base as shown
in the image.
A
.
Intel Socket 1366/1156/1155/775 Installation
Extension Fan Cable
Intel Clip
Cooler Fan connector
