8
i3 NEO
1. Removing the side panels
I/O Ports
# Part # Part # Part # Part
ⓐ Power Button ⓑ Reset Button ⓒ HDD / Power LED ⓓ Microphone Jack
ⓔ Headphone Jack ⓕ USB 2.0 Port ⓖ USB 3.0 Ports
2. Removing the front panel
ⓐ ⓑ ⓒ ⓓ ⓔ ⓕ ⓖ
