Zamil PV036 - Model Decoding

1& 2
BASIC
3, 4 & 5
NOMINAL COOLING
CAPACITY
(MBH)
6
ELECTRICAL
SUPPLY
( V-Ph-Hz )
9
BLOWER
MOTOR
13
EVAPORATOR
COIL
14
CONDENSER
COIL
15
FILTER
11
HEATER
16
UNIT
ACCESSORIES
PV
VERTICAL
PACKAGED
UNIT
036 048 060
H : 208/230-3-60 M: 380-3-60
*
(4 WIRE)
V : STD.
MOTOR
A : ALUMINUM FIN B : COATED
ALUMINUM FIN
C :COPPER FIN
N :NO HEATER
N : STD. UNIT
MODEL DECODING
8
COMPRESSOR
TYPE
S : SCROLL
HERMETIC
R :RECIPRO-
CATING HERMETIC
N :DIRECT DRIVE
10
DRIVE
OPTIONS
19
DIS-
CHARGE
(SUPPLY
AIR)
18
OPTIONS
12
COND.
MOTOR
N : STD.
A : ALUMINUM FIN B : COATED
ALUMINUM FIN
C :COPPER
FIN
17
APPLICATIONS
N : STANDARD
APPLICATION
C :COMMUNICA-
TION SHELTER APPLICATION
20
ACCESS
F: FRONT
NOTE:
*
Not available for PV036.
7
REFRIGE-
RATION
CIRCUIT
S : SINGLE
N :NO
FILTER
G:
2" PLEATED FILTER
N : STD.
R :RH L :LH
