Zanotti BAS235T02F - Page 46

DATA:
REV.nr. FOGLIO nr :
DI
33
BDB235NO368F
BDB235NO468F/ANP
AA08002
04-04-2003Soncini
DISEGNO nr.
ApprovatoDisegnato
Soncini
DATA: Approvato
MODELLO
BDB235TO02F-02F/ANP-152F-186F-195F-212F
BDB235TO296F-315F-317F/ANM-86F-151F
EVAPORATORCONDENSING UNIT
TO X3
TO X2
TO X2
FROM X1
FROM X1
FROM X1
RIGHT
LEFT
CAVO DI LINEA
( LINE CABLE )
COMPRESSORE
(COMPRESSOR)
MACCHINA
( UNIT )
CAVO COMPRES.
(COMPRES. CABLE)
VENTOLA COND. VENTOLE EVAP.
(CONDEN. FAN) (EVAP. FANS)
SBRINAMENTO
(DEFROST)
CARATTERISTICHE GENERALI E ASSORBIMENTI
MORSETTIERE
BDB235TO...F e BDB235TO...G MTZ100HS4=MT100HS4=22,0 A max. I max.=6,8 A In=2,3 A In tot.=1,24 A 4 x 4 mmq 5 x 6 mmq
BDB235NO368F MTZ80HP4=23,0 A max. I max.=6,8 A In=2,3 A In tot.=1,24 A 4 x 4 mmq 5 x 6 mmq
BDB235NO468F/ANP LTZ50HP4=12,0 A max. I max.=6,8 A In=2,3 A In tot.=1,24 A 4 x 4 mmq 5 x 6 mmq
