46
oE
P2 calibration
0
P3C
P3 configuration
nP
o3
P3 calibration
0
P4C
P4 configuration
nP
o4
P4 calibration
0
CLt
ON/OFF percentage (C.R.O.)
tMd
Time remaining before next defrost activation (only for interval defrost)
LSn
Number of devices in LAN
2
LAn
List of address of LAN devices
2
Adr
Modbus address
1
rEL
Firmware release
Ptb
Parameter table
10
Pr2
PR2 access
SEt
Set point
-15
SEZ
LAN working mode
1
SH
Browsing SuperHeating
oPP
Percentage thermostatic valve output
dP1
Browsing probe P1
dP2
Browsing probe P2
dP3
Browsing probe P3
dP4
Browsing probe P4
dP5
Browsing probe P5
dP6
Value P6 temperature probe
dPP
Value probe P6 pressure
rPP
Value remote probe pressure
rCP
Value remote P4 probe
Lt
Browsing minimum temperature detected
Ht
Browsing maximum temperature detected
dPr
Browsing thermostat virtual probe
dPd
Browsing defrost virtual probe
dPF
Browsing fans virtual probe
rSE
Browsing Set adjustment (SET + ES + SETd)
17 Signal and alarm from digital inputs
“CA” flashing
Meaning : switch-on of high pressure switch
Outputs behaviour : all ouputs switch-off and general alarm output switch on
Delay of alarm : 0 seconds
“PrP” flashing
Meaning : switch-on of low pressure switch “nPS” times in time base of “d2d” minutes
→ probable gas leakage
Outputs behaviour : all ouputs switch-off , general alarm output switch-on and propane alarm output switch-on
“dA” flashing
Meaning : door open
Ouputs bahaviour : all outputs don’t change and general alarm output switch-on
Delay of alarm : 15 minutes
