• Make sure that children or pets do not climb inside the
drum.
Product description
1
3
4
2
5
6
7
1
Control panel
2
Door
3
Fluff filter
4
Rating plate
5
Adjustable feet
6
Sideways vent outlets / back vent outlet
7
Ring nut
Control panel
1 2 3 4 5
4
