Step 3 Close the oven door halfway to the
first opening position. Then lift and
pull forward and remove the door
from its seat.
Step 4 Put the door on a soft cloth on a stable
surface and release the locking system
to remove the internal glass panel.
Step 5 Turn the fasteners by 90° and remove
them from their seats.
Step 6 First lift carefully and then remove the
glass panel.
Step 7 Clean the glass panels with water and soap. Dry the glass panels carefully. Do not clean the glass
panels in the dishwasher.
Step 8 After cleaning, install the glass panel and the oven door.
When installed correctly the door trim clicks.
Make sure that you install the internal glass panel in
the seats correctly.
10.5 How to replace: Lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
Before you replace the lamp:
Step 1 Step 2 Step 3
Turn off the oven. Wait until the
oven is cold.
Disconnect the oven from the
mains.
Put a cloth on the bottom of the cav‐
ity.
16 ENGLISH
