zapco DSP-Z8 III User Manual

All Zapco DC series amplifiers, and the Zapco DSP-Z8, stand-alone Digital Signal Processor incorporate
Zapco's exclusive Digital Programming Network (DPN).
This network allows the user to program all amp functions of all DC amps in the system, using a single
PC screen. Each Digital Control product has a USB interface. This allows you to plug a PC into any unit
on the network and control the entire network.
The amp's DIP Switch allows you to address each
amplifier to it's own location on the network.
Then when you call up the amp for
programming, it will even identify itself by its
location and its model number.
USB input allows a PC to be hooked directly to
the amp with a standard USB cable. The DRC-
SL also has a USB port so the PC can be
plugged in at the dash,without disturbing the
installation.
Both I/0 Data ports are bi-directional.
One connects to the control direction,
while the other connects to the next
amp in the network.
To Next Amplifier
To Control
The DSP-Z8 and the Digital Programming Network
6
