8
ST-1B Input/Controls Ends
The ST-1B has similar functions as the other ST-B amps but the 1 channel layout
puts the controls in different positions. Plus the ST-1B has a remote control port.
1• RCA inputs
2• RCA outputs
3• Variable gain control (set to minimum
before initial turn-on)
4• Crossover function selector for full range
of low pass
5• Low Pass frequency control
6• Sub Sonic filter
7• 0-180° Phase control
8• 0-12 dB Bass boost control
9• Remote control port
10• Power/protect LED
3
2
4 7
6 10
1
5
8
9
