Page 4-38 105SL Maintenance Manual 32056L Rev. 2 12/4/01
SECTION 4 PREVENTIVE AND CORRECTIVE MAINTENANCE
3HHO2II0RGH
In peel-off mode, the lower roller alignment has the same effect on media tracking as the
rewind plate alignment does in rewind mode. Refer to Figure 4-28 and perform the following
procedure.
Figure 4-27. Rewind Plate Assembly
Figure 4-28. Peel-Off Lower Roller Alignment
Lower
Roller
Screws
Side Plate
Platen
Support
Bracket
To Next Page
