Page 5-4 105SL Maintenance Manual 32056L Rev. 2 12/4/01
SECTION 5 MAINTENANCE AND ASSEMBLY DRAWINGS
*Only available in quantities of 25 as Part Number HW46015
**Only available in quantities of 100 as Part Number HW07435
***Only available in quantities of 50 as Part Number HW30392-004
†Only available in quantities of 25 as Part Number HW30256-B
Table 5-1. Final Assembly (View 1)
Item Part Number Description Qty
1 31040 Panel, Media Side 1
2 30269 Pad, PVC 4.00 x 0.037 x 0.62 2
3 01861 Label, Supplies 1
4 32039M Kit, Maintenance, Media Cover 1
5 30407-008 . Screw, 6-32 x 0.5 4
6 01130 Nut, 6-32 4
7 40051M Assy., Ribbon Supply Spindle (See Pages 5-18 & 5-19) 1
8 40050M Assy., Ribbon Take-up Spindle (See Pages 5-20 & 5-21) 1
9 32038M Kit, Electrical Cover 1
10 46396-006 Screw, 6-32 x 0.37, Phillips 2
11 32034M Assy., Pivot Bar (See Page 5-25) 1
12 46609-4M Take Label Sensor (See Pages 5-28 & 5-29) 1
13 Roller, Main Platen (See Pages 5-14 & 5-15 for Platen Roller Kits) 1
14 48808 Bar, Peel/Tear 1
15 30023 Plate, Cover Cutter 1
16 Screw, 6-32 x 0.25 2
17
Bumper 4
18
Screw, Lock Hex, 6-32 x 0.37 4
19 46198M
Kit, Maintenance, Stepper Motor/Pulley 203dpi 1
46199M
Kit, Maintenance, Stepper Motor/Pulley 300dpi 1
20
30826 Plug, Hole 2
21
%† Nut, Thumb 6-32 x 0.50 2
22 48342 Bracket, Front Cover 1
23 32053M Assy., Media Hanger (See Page 5-17) 1
Bold = Part available for purchase
Light italic = Part not available for purchase, listed and shown for reference only
