Page 5-6 105SL Maintenance Manual 32056L Rev. 2 12/4/01
SECTION 5 MAINTENANCE AND ASSEMBLY DRAWINGS
*Only available in quantities of 50 as Part Number HW30392-004
**Only available in quantities of 25 as Part Number HW06268
†Only available in quantities of 25 as Part Number HW30392-008
Table 5-2. Final Assembly (View 2)
Item Part Number Description Qty
1 Screw, 6-32 x 0.25 9
2 01130 Nut, 6-32 1
3 22613M Kit, Maintenance, Head Open Sensor 1
4 38226M Kit, Maintenance, Reflective Sensor (Includes Tiewrap Q06020) 1
5 46091 Grommet, Rubber 1.25 x 0.625 1
6 40305RM Assy., Media Guide Support (See Page 5-22) 1
7 32028M Kit, Maintenance, Media Sensors (Upper and Lower) 1
8 30236 . Screw, 4-40 x 0.25 1
9 30494 . Washer, 0.32 x 0.119 x 0.062 1
10 35020 . Bracket, Media Sensor 1
11 40031 . Cover, Sensor Wire 1
12 40248 Plate, Shaft Wear 1
13 40154 Pin, Eccentric 1
14 :DVKHU/RFN 1
15
† 6FUHZ[ 1
16 30956 Washer, Flat 0.207 x 0.146 x 0.030 2
17 30007-3 Shaft, Roller 0.187 x 6.50 1
18 48011-5 Roller 1
Bold = Part available for purchase
Light italic = Part not available for purchase, listed and shown for reference only
To Next Page
