32056L Rev. 2 12/4/01 105SL Maintenance Manual Page 5-17
MAINTENANCE AND ASSEMBLY DRAWINGS SECTION 5
*Only available in quantities of 25 as Part Number HW35136
**Only available in quantities of 25 as Part Number HW30466
†Only available in quantities of 25 as Part Number HW35137
Table 5-7. Media Supply Hanger
Item Part Number Description Qty
1 32053M Kit, Maintenance, Media Supply Hanger 1
2 35082 . Guide, Media 1
3 35136* . Washer, Nylon 0.252 x 0.472 x 0.059 2
4 . Bracket, Media Hanger 1
5 30466** . Washer, 0.26 x 0.63 x 0.06 1
6 35137
† . Ring, Retainer 0.250 Diameter 1
Bold = Part available for purchase
Light italic = Part not available for purchase, listed and shown for reference only
Figure 5-7. Media Supply Hanger
1
2
3
4
3
5
6
